WRD-650 UG Square Cover Flange to SMA Female Waveguide to Coax Adapter (6.5 GHz to 18 GHz)
Who It's For & Why It's Great
The WRD-650 UG Square Cover Flange to SMA Female waveguide adapter is engineered for RF and microwave engineers who demand reliable signal transmission across broadband frequency ranges. This waveguide to coax adapter seamlessly converts WR-650 waveguide signals to SMA female connectors, making it ideal for test equipment, satellite communications, radar systems, and high-frequency laboratory applications. Operating from 6.5 GHz to 18 GHz, this adapter delivers low insertion loss and exceptional return loss performance, ensuring signal integrity in mission-critical RF systems. The UG square cover flange design provides secure mechanical coupling while maintaining electrical performance across the entire frequency band.
Key Features
- Frequency range: 6.5 GHz to 18 GHz broadband operation
- UG square cover flange waveguide interface for secure mechanical mounting
- SMA female connector output for standard coaxial cable integration
- Low insertion loss and excellent return loss characteristics
- Precision-engineered for repeatable, reliable RF performance
- Compact design suitable for rack-mount and benchtop test systems
- Ideal for radar, satellite, and microwave communication applications
Technical Specifications
| Specification |
Value |
| Manufacturer |
STRATEGIC SOURCING |
| Part Number |
PEWCA1117 |
| Product Type |
Waveguide to Coax Adapter |
| Waveguide Interface |
WR-650 UG Square Cover Flange |
| Coax Interface |
SMA Female |
| Frequency Range |
6.5 GHz to 18 GHz |
| Impedance |
50 Ohms |
| Application |
RF/Microwave Test, Radar, Satellite Communications |
Frequently Asked Questions
What is a waveguide to coax adapter used for?
A waveguide to coax adapter converts signals between waveguide transmission lines and standard coaxial cables. This WRD-650 adapter enables connection of WR-650 waveguide systems to SMA-equipped test instruments, amplifiers, and receivers, making it essential for RF measurement and system integration.
What frequency range does the WRD-650 adapter support?
The WRD-650 UG square cover flange adapter operates across a 6.5 GHz to 18 GHz frequency range, covering Ku-band and portions of X-band, making it suitable for satellite, radar, and broadband microwave applications.
How does the UG square cover flange improve performance?
The UG square cover flange design provides superior mechanical alignment and electrical shielding compared to standard flanges. This ensures consistent impedance matching, minimizes reflections, and maintains low insertion loss across the entire frequency band.
Is this adapter suitable for laboratory and field applications?
Yes. The WRD-650 waveguide to coax adapter is designed for both benchtop test environments and field deployment in radar, satellite ground stations, and microwave communication systems where reliable RF signal conversion is critical.
