VIVOTEK AW-GEV-288A-370 28-Port Managed PoE Switch
The VIVOTEK AW-GEV-288A-370 is a professional-grade 28-port managed PoE switch engineered for large-scale surveillance systems and enterprise network deployments. With 24 Gigabit PoE ports and 4 Gigabit combo uplink ports, this Layer 2 managed switch delivers reliable power and data connectivity to IP cameras, access points, and networked devices. Supporting 802.3 af/at/bt hybrid PoE standards with up to 90W per port and a total 370W power budget, it's ideal for organizations requiring centralized device management, DHCP server functionality, and Non-Stop PoE redundancy for mission-critical surveillance infrastructure.
Key Features
- 24 Gigabit PoE ports with 802.3 af/at/bt hybrid support
- 4 Gigabit combo uplink ports for flexible network expansion
- 90W maximum power per port for high-power PoE devices
- 370W total PoE power budget for simultaneous multi-device operation
- Layer 2 managed switch with advanced VLAN and QoS capabilities
- Built-in DHCP server for simplified IP camera deployment
- Device List function for centralized network monitoring
- Non-Stop PoE technology ensures continuous power during system transitions
- Industrial-grade reliability for 24/7 surveillance operations
Technical Specifications
| Specification |
Details |
| Manufacturer |
VIVOTEK USA |
| Model Number |
AW-GEV-288A-370 |
| Port Configuration |
24x Gigabit PoE + 4x Gigabit Combo Uplink |
| PoE Standards |
802.3 af/at/bt Hybrid |
| Maximum PoE Power per Port |
90W (802.3bt) |
| Total PoE Budget |
370W |
| Switch Type |
Layer 2 Managed |
| Network Management |
DHCP Server, Device List, Non-Stop PoE |
| Typical Applications |
IP Surveillance, Access Control, Network Infrastructure |
Frequently Asked Questions
What is a managed PoE switch and why do I need one?
A managed PoE switch combines Power over Ethernet delivery with advanced network management features. Unlike unmanaged switches, it allows you to configure VLANs, prioritize traffic, and monitor connected devices—essential for professional surveillance systems where reliability and security matter. The VIVOTEK AW-GEV-288A-370 adds centralized device management and DHCP server capabilities, simplifying deployment of multiple IP cameras.
Can this 28-port PoE switch power high-wattage cameras?
Yes. With 90W per port support and 802.3bt hybrid PoE compatibility, the AW-GEV-288A-370 powers demanding devices like PTZ cameras, thermal imaging systems, and multi-sensor units. The 370W total budget accommodates simultaneous high-power draws across multiple ports, making it suitable for large surveillance deployments.
What does Non-Stop PoE mean?
Non-Stop PoE ensures connected devices maintain power during system restarts or configuration changes. This feature is critical for surveillance systems where camera downtime creates security gaps. The AW-GEV-288A-370 guarantees uninterrupted operation of your entire network infrastructure.
Is the VIVOTEK managed switch suitable for outdoor or harsh environments?
The AW-GEV-288A-370 is designed for industrial-grade reliability in commercial and surveillance settings. For outdoor installations, pair it with appropriate environmental enclosures. Its Layer 2 management capabilities and redundant uplink ports ensure stable operation in demanding network environments.
