VisionTek PoE Injector - Gigabit 24 Port IEEE 802.3bt On Board OLED Managed PoE Injector - No Power supply
GBT 24 Port
Managed PoE Injector for PoE Lighting
The high density Midspan GBT-24-M converts any switch or PoE switch into an 80 watt per port PoE (IEEE 802.3bt Type 3) Power Sourcing Equipment for PoE lighting, A/V applications, or Node Centric PoE architecture. The on board, highly visible OLED provides an intuitive Layer 1 control as well as real time monitoring by port of status and power performance of the port.
Key Features
- Provides 80 watt per port output for PoE Lighting, A/V Applications or Node Centric PoE Architecture
- Works with Digital Electricity for alternate infrastructure applications
- Layer 1 Port Management through the intuitive on board OLED screen and push button controller
- Active IEEE 802.3bt negotiation on Mode A and Mode B with power capacity up to 60 watts and a managed passive configuration up to 80 watts per port
- Designed to occupy one unit of a 19" server rack
- Renders a cost effective and easy to implement alternative to expensive, complicated infrastructure
- On-board automatic cooling fan
- Input 48-55v DC - Includes two 2.1 x 5.5 mm DC inputs
- Provides 80 watt per port output for PoE Lighting, A/V Applications or Node Centric PoE Architecture
- Works with Digital Electricity for alternate infrastructure applications
- Layer 1 Port Management through the intuitive on board OLED screen and push button controller
- Active IEEE 802.3bt negotiation on Mode A and Mode B with power capacity up to 60 watts and a managed passive configuration up to 80 watts per port
- Designed to occupy one unit of a 19" server rack
- Renders a cost effective and easy to implement alternative to expensive, complicated infrastructure
- On-board automatic cooling fan
- Input 48-55v DC - Includes two 2.1 x 5.5 mm DC inputs
Product Type: PoE Injector
Certifications & Standards:
IEEE 802.3bt
Rack Height: 1U
Brand Name: VisionTek
Compatibility:
PoE Lighting
Form Factor: Rack Mountable
Manufacturer: VisionTek Products, LLC
Product Model: GBT-24-M
Product Name: GBT-24-M PoE Injector
Manufacturer Part Number: 600015
Manufacturer Website Address: http://www.visiontek.com
Limited Warranty: 1 Year
Weight (Approximate): 4.50 lb
