Supports 4K resolutions – up to 3840 x 2160 @ 60Hz
Support USB-C to HDMI video signal
4 inputs 4 outputs (Inputs：4*USB–A & 4*USB-B)
KVM function Share one set of mouse ,keyboards , screen and operate on individual source
Support HDMI 2.0 standard /HDCP 2.2 compliant
High frequency range：25MHz~600MHz
DTS® HD, Dolby® TrueHD digital audio compliant
Expand 2 HDMI sources on your HDTV devices
USB 3.1 GEN1 TYPE C input supports Android Phone、PC and Mac , I pad pro_2019
Supports Samsung DeX® Mode & Huawei MUEI model
NOTE: The software has vulnerabilities with the Web UI implementation. These vulnerabilities could lead to Denial of Service and Privilege Escalation. This model has been discontinued.
Few sample applications:
OREI UKM-404 4K at 60Hz KVM switch ideal device for multitasking on a Single Monitor, You can take control of three devices such as PC, Computer, Laptop, Android Smartphones, Streaming Box, PS4/PS5 gaming devices or 4K Blu-ray Players on a single Monitor. You can use a set of USB Keyboard to control everything.
Support resolution up to 4K@60Hz YUV4:4:4 chroma sampling, making display image more exquisite and realistic, really give a feast for your eyes.
It also supports 3D and 1080P or lower resolution. 4K KVM Switch can full meet the needs of family and Office. Supports PCM, Dolby True HD, DTS-HD Master Audio up to 7.1 Ch. Digital and analog Audio output. Type C input supports Android Phones, PC and Mac, iPad Pro, For Video Output through USB-C Port, it must support DP Alt Mode.
[summary]
2 HDMI input + Dual USB and 1 USB-C into 2 output Matrix Switcher
Full 18G bandwidthbr>
USB 3.1 GEN1 Type C input supports Android Phones for Video Output through USB-C Port
[/summary]
[tab1]
FAQs
You can use standard HDMI cables up to 15 feet and high quality cables up to 30 feet.
However, you can use fiber optic active HDMI cables up to 200 feet. If its not a high quality cable then you may lose the signal in some instances.
You can use standard HDMI cables up to 15 feet and high quality cables up to 30 feet.
However, you can use fiber optic active HDMI cables up to 200 feet. If its not a high quality cable then you may lose the signal in some instances.
No, our switchers aren't compatible with capture cards
Yes, the included power adapter does support 220V
[/tab1]
[shortdes]
Video resolution up to 4K@60Hz - HDR
Supports KVM
Compliance: HDMI 2.0 - HDCP 2.2
[/shortdes]
[tab]
AUDIO AND VIDEO
Input:
INPUT PORTS:
4xUSB
Input Connector:
4xUSB-A
USB Standard:
USB 3.0 Gen1
Output:
OUTPUT PORTS:
4xUSB
Output Connector:
4xUSB-B
USB Standard:
USB 3.2 Gen1
CONTROL
Control Port
1xIR IN, 1xRS232, 1xTCP/IP
Control Connector
1x3.5mm Mini Jack, 1x3-pin Terminal Blocks, 1xRJ45
Bandwidth
5Gbps
POWER
Power Supply:
DC24V1.25A
Power Consumption
28W(Max)
ENVIRONMENTAL
Operating Temperature:
10 ~ +55°C
Storage Temperature:
-25 ~ +70°C
Relative Humidity
10% - 90%
DIMENSIONS & WEIGHT
Height
36 mm
Width
200mm
Depth
153mm
Weight
600g
REGULATORY
Safety and Emission:
CE | FCC
PACKAGE CONTENTS
1x UKM-404
2x Mounting Ears with 4 Screws
4x Plastic Cushions
1x RS232 cable
1x IR Receiver
1x Remote control
1x USB3.2 cable (USB-A to USB-B, 1m)
1x Power Adapter (DC 24V/1.25A)
1x User Manual
Warranty
1 - Year Manufacturer's Warranty
[/tab]
General Information
UPC
0850031132030
