Tycon TPDIN-SC48-20 V3 - 48V 20A MPPT Solar Charger with Integrated PoE Switch
The TPDIN-SC48-20 V3 is a web-manageable 48V 20A MPPT solar charger engineered for remote and off-grid power applications. This integrated solution combines a high-efficiency MPPT solar controller, 48V battery charging system, and 7-port Gigabit PoE switch in a single compact unit. Perfect for wireless networks, surveillance systems, and remote monitoring stations that require reliable solar power and network connectivity.
Designed for system integrators and network operators, this MPPT solar controller supports both SLA and lithium battery chemistries, delivering intelligent charging with remote management capabilities. The built-in 7-port Gigabit PoE switch provides 802.3at and 24V passive PoE outputs, eliminating the need for separate power distribution equipment in remote deployments.
Key Features
-
20A MPPT Solar Charging — Maximum Power Point Tracking for optimal solar panel efficiency and faster battery charging
-
48V Battery Management — Supports SLA and lithium battery types with intelligent charge regulation
-
7-Port Gigabit PoE Switch — 802.3at PoE and 24V passive PoE outputs for powering remote devices
-
Web-Based Remote Management — Monitor and control charging, battery status, and PoE distribution from anywhere
-
Compact All-in-One Design — Integrates solar charging, battery management, and network switching in one unit
-
Off-Grid Ready — Ideal for remote locations without grid power access
-
Firmware Support — Tycon Systems firmware enables advanced remote control and monitoring features
-
Industrial-Grade Construction — Built for harsh outdoor and remote environments
Technical Specifications
| Specification |
Details |
| Manufacturer |
Tycon Systems |
| Model |
TPDIN-SC48-20 V3 |
| Solar Charging |
20A MPPT Controller |
| Battery Voltage |
48V DC |
| Battery Types Supported |
SLA (Sealed Lead Acid), Lithium |
| Network Switch |
7-Port Gigabit Ethernet |
| PoE Standards |
802.3at, 24V Passive PoE |
| Management Interface |
Web-Based Remote Management |
| Firmware |
Tycon Systems Supported |
| Application |
Off-Grid, Remote Power, Wireless Networks, Surveillance |
Frequently Asked Questions
What is an MPPT solar controller and why does the TPDIN-SC48-20 V3 use one?
MPPT (Maximum Power Point Tracking) is an advanced charging algorithm that continuously optimizes the solar panel output to extract maximum available power. The 20A MPPT solar charger in the TPDIN-SC48-20 V3 increases charging efficiency by 20-30% compared to standard PWM controllers, resulting in faster battery charging and better performance in variable sunlight conditions.
Can the TPDIN-SC48-20 V3 work with both SLA and lithium batteries?
Yes. The 48V battery management system supports both SLA (Sealed Lead Acid) and lithium battery chemistries. The controller automatically adjusts charging parameters based on the selected battery type, ensuring optimal lifespan and performance for either chemistry.
How does the integrated PoE switch benefit remote installations?
The built-in 7-port Gigabit PoE switch eliminates the need for separate power injectors and network switches. It delivers both data and power over Ethernet to remote devices like wireless access points, IP cameras, and sensors, reducing equipment count, installation complexity, and total system cost in off-grid deployments.
What remote management features does the TPDIN-SC48-20 V3 offer?
The web-manageable interface provides real-time monitoring of solar charging status, battery voltage and state of charge, PoE port status, and system health. Remote management capabilities enable firmware updates, configuration changes, and troubleshooting without physical site visits, ideal for distributed remote power systems.
