Tycon Systems UPS24-100-120 UPSPro® 24V Outdoor Backup Power System
The UPS24-100-120 is a rugged 24VDC outdoor backup power system engineered for telecom, networking, and remote site applications requiring continuous uptime. This 120W backup power solution maintains critical equipment operation during mains failures, delivering reliable 24VDC output from a weatherproof aluminum enclosure. With 100Ah sealed lead acid AGM batteries and optional solar integration, the UPSPro® extends backup runtime while reducing operational costs. Ideal for outdoor cabinets, base stations, and distributed infrastructure where power reliability directly impacts service delivery.
Key Features
- 120W maximum output power with 100W continuous load capacity
- 100Ah maintenance-free sealed lead acid AGM battery bank
- 24VDC system voltage for standard telecom and networking equipment
- Integrated 20A PWM solar/battery charge controller with load management
- Weatherproof UV-resistant aluminum outdoor enclosure
- Dual AC input support: 120/240VAC mains charging
- Automatic overcharge and over-discharge protection
- Optional solar panel integration for extended backup runtime
- Sealed AGM batteries require zero maintenance
- Flexible load control for priority device management
Technical Specifications
| Specification |
Value |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
UPS24-100-120 |
| Output Power (Maximum) |
120W |
| Continuous Load Rating |
100W |
| System Voltage |
24VDC |
| Battery Capacity |
100Ah sealed lead acid AGM |
| AC Input Voltage |
120/240VAC |
| Charge Controller |
20A PWM with load control |
| Enclosure Material |
Aluminum (UV-resistant) |
| Environmental Rating |
Outdoor weatherproof |
| Solar Integration |
Optional (via PWM controller) |
Frequently Asked Questions
What is the backup runtime for the UPS24-100-120?
Backup runtime depends on load and battery capacity. With a 100W continuous load on the 100Ah battery bank, you can expect approximately 10 hours of backup power. Adding solar panels extends runtime indefinitely during daylight hours. For precise calculations, contact Tycon Systems with your specific load profile.
Can this 24VDC outdoor backup power system work with solar panels?
Yes. The integrated 20A PWM solar charge controller supports optional solar panel integration, allowing you to recharge batteries from renewable energy and extend backup availability. This makes the UPSPro® ideal for remote locations without reliable grid access.
Is the sealed lead acid battery maintenance-free?
Absolutely. The 100Ah AGM batteries are maintenance-free sealed units requiring no water top-ups or terminal cleaning. They're designed for outdoor deployment and operate reliably in harsh environmental conditions within the weatherproof aluminum enclosure.
What equipment can I power with this 120W backup power system?
The 24VDC output supports standard telecom equipment, networking devices, outdoor cabinets, base station controllers, and remote monitoring systems rated for 24V operation. Verify your equipment's voltage and power requirements (max 100W continuous) before installation.
