Tycon Systems UPL12/24-200-600 UPSPro® Outdoor Uninterruptible Power System
The Tycon Systems UPL12/24-200-600 UPSPro® is a professional-grade outdoor UPS system engineered for mission-critical applications requiring continuous DC power in remote and demanding environments. This configurable 12/24VDC uninterruptible power supply delivers 450W output power backed by a robust 200Ah sealed lead acid battery, providing approximately 2400Wh of reliable backup energy. Ideal for telecommunications infrastructure, renewable energy systems, remote monitoring stations, and outdoor networking equipment, this UPS ensures zero downtime during power interruptions.
Key Features
- Configurable 12VDC or 24VDC output for flexible system design
- 450W continuous output power capacity
- 200Ah sealed lead acid (SLA) battery with 2400Wh total energy storage
- Rugged outdoor-rated enclosure for harsh environmental conditions
- Automatic switchover to battery backup during power loss
- Integrated battery management and monitoring
- Low-maintenance sealed battery technology
- Compact form factor for space-constrained installations
Technical Specifications
| Specification |
Value |
| Manufacturer |
Tycon Systems |
| Model Number |
UPL12/24-200-600 |
| System Type |
Configurable 12VDC / 24VDC UPS |
| Output Power |
450W |
| Battery Type |
Sealed Lead Acid (SLA) |
| Battery Capacity |
200Ah |
| Total Energy Storage |
2400Wh |
| Input Voltage Range |
12/24VDC (configurable) |
| Backup Runtime |
Varies by load and configuration |
| Operating Temperature |
-40°C to +60°C (typical outdoor range) |
| Enclosure Rating |
Outdoor-rated, weather-resistant |
Frequently Asked Questions
What is the runtime backup provided by the UPL12/24-200-600 UPS system?
The UPSPro® 12/24V outdoor UPS delivers approximately 5+ hours of backup runtime at half-load conditions (225W), with runtime varying based on actual load draw and battery age. The 2400Wh capacity ensures extended protection for critical remote applications.
Can the UPL12/24-200-600 be configured for both 12V and 24V applications?
Yes, the Tycon Systems UPSPro® is fully configurable as either a 12VDC or 24VDC system, allowing flexibility for diverse outdoor power backup requirements including telecommunications, solar installations, and remote monitoring equipment.
Is the 200Ah SLA battery replaceable and how long does it last?
The sealed lead acid battery in this outdoor UPS system is designed for 5-7 years of service life under normal operating conditions. Replacement batteries are available from Tycon Systems and can be easily swapped for continued operation.
What outdoor environments is the UPL12/24-200-600 rated for?
The UPSPro® 450W outdoor UPS operates reliably in extreme conditions from -40°C to +60°C, making it suitable for remote towers, weather stations, renewable energy systems, and harsh industrial applications requiring continuous DC power backup.
