Tycon Systems RemotePro 100W Off-Grid Solar Power System with 1440W Solar Array
The RemotePro RPSTL24/48M-400-1440 is a complete off-grid solar power system engineered for mission-critical remote applications requiring reliable, uninterrupted power delivery. This 1440W solar solution combines a massive 400Ah SLA battery bank with intelligent MPPT charge control to provide 100W continuous output at selectable 24V or 48V. Perfect for remote telecommunications, surveillance, weather stations, and distributed energy systems operating in low-sun or challenging environments, this system delivers 4800Wh of energy storage for extended autonomy without grid dependency.
Key Features
- 100W continuous remote power output with 24V/48V selectable configuration
- 1440W solar array for maximum energy harvesting in variable sunlight
- 400Ah SLA battery bank providing 4800Wh total energy storage capacity
- High-efficiency MPPT charge controller for optimal solar conversion
- 30A output capability for demanding remote equipment loads
- Complete integrated system — no additional components required
- Rugged outdoor-rated enclosure for harsh environmental conditions
- Low-maintenance sealed lead-acid battery technology
Technical Specifications
| Specification |
Value |
| Manufacturer |
Tycon Systems |
| Part Number |
RPSTL24/48M-400-1440 |
| Product Line |
RemotePro |
| Continuous Power Output |
100W |
| Output Voltage Options |
24V or 48V DC |
| Maximum Output Current |
30A |
| Solar Array Capacity |
1440W |
| Battery Type |
Sealed Lead-Acid (SLA) |
| Battery Capacity |
400Ah |
| Total Energy Storage |
4800Wh |
| Charge Controller |
MPPT (Maximum Power Point Tracking) |
| Application |
Off-grid remote power systems |
Frequently Asked Questions
What is an off-grid solar power system and how does it work?
An off-grid solar power system operates independently from utility power, using solar panels to generate electricity that charges a battery bank for 24/7 power availability. The RemotePro system uses its 1440W solar array to continuously charge the 400Ah battery, while the MPPT controller optimizes energy conversion. This design ensures reliable power in remote locations without grid infrastructure.
How long will the 4800Wh battery provide power at 100W continuous output?
At 100W continuous draw, the 4800Wh energy storage provides approximately 48 hours of autonomous operation before requiring solar recharge. Actual runtime depends on weather conditions, load patterns, and battery age. The 1440W solar array ensures rapid recharge cycles even in low-light environments.
Can I choose between 24V and 48V output for my remote power application?
Yes, the RemotePro system offers selectable 24V or 48V output configuration, allowing you to match your specific remote equipment requirements. Higher voltage (48V) reduces current draw and cable losses over long distances, while 24V may be preferred for certain legacy systems.
What remote applications is this 1440W solar system best suited for?
This remote power system excels in telecommunications towers, remote surveillance networks, weather monitoring stations, distributed antenna systems (DAS), cathodic protection systems, and any critical infrastructure requiring autonomous, maintenance-free power in off-grid locations.
