Tycon RemotePro 85W Series Off-Grid Remote Power System
The RemotePro RPS1224-100-85 is a complete off-grid power system engineered for remote equipment installations requiring reliable, continuous power in locations without grid access. This 24V passive PoE power system delivers 30W continuous output with integrated 100Ah battery storage and 85W solar generation, making it ideal for wireless access points, surveillance cameras, and remote networking equipment that demand extended runtime and weatherproof reliability.
Built for harsh outdoor environments, this remote power solution combines a high-capacity 100Ah battery bank, efficient solar charging, and dual output options into a single weatherproof enclosure. With over 35 hours of reserve runtime at rated load and a 3-year manufacturer warranty, the RemotePro 85W Series provides the dependability required for mission-critical remote deployments.
Key Features
- 24V passive PoE output up to 30W continuous power delivery
- 100Ah lithium-ready battery bank for extended off-grid runtime
- 85W solar panel with integrated mounting hardware
- 12VDC 1.5A auxiliary output for secondary devices
- Approximately 17W continuous load capacity with 35+ hour reserve time
- Weatherproof outdoor enclosure rated for extreme conditions
- Passive PoE technology eliminates active power injection complexity
- 3-year manufacturer warranty and technical support
Technical Specifications
| Specification |
Value |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
RPS1224-100-85 |
| Primary Output |
24V Passive PoE, 30W Maximum |
| Auxiliary Output |
12VDC, 1.5A |
| Battery Capacity |
100Ah |
| Solar Panel Rating |
85W |
| Continuous Load |
~17W |
| Reserve Runtime |
35+ hours at rated load |
| Enclosure Rating |
Weatherproof Outdoor |
| Warranty |
3 Years |
Frequently Asked Questions
What is a passive PoE power system and how does it work?
Passive PoE (Power over Ethernet) delivers power directly over standard Ethernet cables without active power injection. The RemotePro RPS1224-100-85 provides 24V passive PoE output, allowing compatible remote equipment to receive both data and power through a single connection, simplifying installation and reducing cable requirements in remote locations.
How long will the 100Ah battery bank power remote equipment?
The 100Ah battery bank provides over 35 hours of reserve runtime at the system's rated 17W continuous load. Actual runtime depends on your specific equipment's power consumption. The auxiliary 12VDC 1.5A output and 24V PoE output can be used simultaneously, allowing flexible power distribution to multiple remote devices.
Is this off-grid power system suitable for year-round remote installations?
Yes. The 85W solar panel combined with the 100Ah battery bank creates a complete off-grid power solution designed for continuous operation. The weatherproof enclosure protects all components from harsh outdoor conditions, and the extended reserve runtime ensures equipment remains powered during low-light periods or seasonal weather variations.
What remote equipment can this 24V PoE system power?
The RemotePro 85W Series powers passive PoE-compatible devices including wireless access points, IP cameras, mesh network nodes, and remote monitoring equipment rated for 24V passive PoE input. The auxiliary 12VDC output supports additional devices requiring lower voltage, providing flexibility for multi-device remote installations.
