Tycon RemotePro RPPL2424-36-30 Solar Power System
The RemotePro RPPL2424-36-30 is a complete remote solar power system engineered for off-grid outdoor deployments where reliable, continuous power is essential. This integrated solution combines a 30W solar panel, 36Ah sealed lead-acid battery, and dual 24V power outputs to deliver 432Wh of stored energy. Perfect for remote networking equipment, surveillance systems, and outdoor electronics, the RPPL2424-36-30 provides weather-resistant operation and maintenance-free performance in harsh environments.
Key Features
- Dual 24V 1.5A and 24V 30W passive PoE outputs for flexible power delivery
- 6.5W continuous 24V output for stable remote equipment operation
- 30W integrated solar panel for renewable energy charging
- 36Ah SLA battery with 432Wh total energy storage capacity
- Weather-resistant outdoor enclosure for harsh climate deployment
- Passive PoE technology eliminates active management requirements
- Sealed lead-acid battery design requires no maintenance
- Complete off-grid power solution for remote locations
Technical Specifications
| Specification |
Value |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
RPPL2424-36-30 |
| Product Line |
RemotePro® |
| Solar Panel Output |
30W |
| Battery Type |
36Ah Sealed Lead-Acid (SLA) |
| Total Energy Storage |
432Wh |
| Primary Output Voltage |
24V DC |
| PoE Output Capacity |
24V 30W (passive PoE) |
| Secondary Output |
24V 1.5A |
| Continuous Output |
6.5W |
| Operating Environment |
Outdoor, weather-resistant |
| Battery Chemistry |
Lead-Acid |
Frequently Asked Questions
What is a remote solar power system and how does it work?
A remote solar power system like the RemotePro RPPL2424-36-30 combines solar charging, battery storage, and regulated power outputs to provide electricity in off-grid locations. The 30W solar panel charges the 36Ah battery during daylight, storing 432Wh of energy for continuous 24V power delivery to remote networking and surveillance equipment.
Can the RPPL2424-36-30 power outdoor networking equipment?
Yes. The 24V 30W PoE output is specifically designed for remote networking devices, wireless access points, and IP cameras. The passive PoE technology delivers power directly over network connections without requiring active management, making it ideal for unattended outdoor deployments.
How long will the 36Ah battery provide power at night?
The 36Ah SLA battery stores 432Wh of energy. Runtime depends on your equipment's power draw. At the 6.5W continuous output rating, the system can sustain operation for extended periods. The 30W solar panel recharges the battery during daylight hours for continuous 24/7 off-grid operation.
Is the RemotePro RPPL2424-36-30 suitable for harsh outdoor environments?
Absolutely. The system features a weather-resistant outdoor enclosure and sealed lead-acid battery design for maintenance-free operation in extreme climates. The integrated solar panel and robust construction make it ideal for remote locations with limited accessibility.
