Tycon RemotePro RPPL1248-20L-35 Off-Grid Solar Power System
The RemotePro off-grid power system is engineered for remote locations requiring reliable, maintenance-free energy independence. This 7.5W continuous power solution combines a 35W solar panel, 240Wh LiFePO4 lithium battery, and integrated PWM solar charge controller to deliver uninterrupted power to surveillance cameras, wireless access points, IoT sensors, and remote networking equipment. Ideal for telecom towers, utility monitoring stations, and off-grid installations where grid power is unavailable or cost-prohibitive, the RemotePro system eliminates fuel costs and generator maintenance while providing clean, renewable energy with passive PoE output for seamless device integration.
Key Features
-
35W Solar Panel — High-efficiency monocrystalline design optimizes energy capture in variable light conditions
-
240Wh LiFePO4 Lithium Battery — Advanced chemistry delivers 3,000+ cycle lifespan with superior thermal stability and safety
-
12V 8A PWM Solar Charge Controller — Integrated controller with load control prevents overcharging and battery damage
-
Dual Power Outputs — 48V 30W passive PoE plus 12V 1.5A auxiliary DC for flexible device compatibility
-
Weatherproof Polycarbonate Enclosure — IP65-rated outdoor housing protects electronics from rain, dust, and UV exposure
-
Pole/Wall Mount Hardware — Side-of-pole solar mount enables quick installation on existing infrastructure
-
7.5W Continuous Power Output — Reliable sustained power delivery for 24/7 remote operations
-
Passive PoE Technology — Powers devices without active management, reducing system complexity
Technical Specifications
| Component |
Specification |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
RPPL1248-20L-35 |
| Solar Panel |
35W monocrystalline |
| Battery Type |
12V 20Ah LiFePO4 (240Wh) |
| Battery Chemistry |
Lithium Iron Phosphate (LFP) |
| Charge Controller |
12V 8A PWM with load control |
| Primary Output |
48V 30W passive PoE |
| Auxiliary Output |
12V 1.5A DC |
| Continuous Power |
7.5W |
| Enclosure Rating |
IP65 weatherproof polycarbonate |
| Mounting |
Pole/wall mount with side-of-pole solar bracket |
| Operating Temperature |
-20°C to +60°C |
| Battery Cycle Life |
3,000+ cycles |
Frequently Asked Questions
What is an off-grid power system and how does it work?
An off-grid power system operates independently from utility power, using renewable energy sources like solar panels to charge batteries that power devices 24/7. The RemotePro system captures sunlight via its 35W solar panel, stores energy in a 240Wh LiFePO4 battery, and delivers consistent 7.5W continuous power through intelligent charge control—perfect for remote locations without electrical infrastructure.
What devices can the passive PoE output power?
The 48V 30W passive PoE output powers compatible IP cameras, wireless access points, and networking equipment designed for passive PoE injection. The system also includes a 12V 1.5A auxiliary output for additional 12V devices, providing flexible connectivity for surveillance, IoT sensors, and remote monitoring applications.
How long does the LiFePO4 battery last?
The 240Wh LiFePO4 lithium battery delivers 3,000+ full charge cycles, significantly outlasting traditional lead-acid batteries (300-500 cycles). With proper maintenance and the integrated PWM charge controller preventing overcharging, the RemotePro battery system provides 8-10+ years of reliable service in remote off-grid installations.
Is the RemotePro system suitable for outdoor installation?
Yes. The system features an IP65-rated weatherproof polycarbonate enclosure that protects internal electronics from rain, dust, and UV damage. Combined with the pole/wall mount hardware and side-of-pole solar bracket, the RemotePro is engineered for permanent outdoor deployment in harsh environmental conditions.
