Tycon RemotePro RPAL48-720-720 Remote Power System
The RemotePro RPAL48-720-720 is a complete 720W remote power solution engineered for off-grid deployments requiring reliable, continuous power. Ideal for remote network installations, telecommunications sites, and outdoor surveillance systems, this off-grid power system delivers 157W continuous output with integrated battery storage and PoE switching capabilities. Whether you're powering remote base stations, wireless access points, or distributed network equipment, the RemotePro provides the rugged reliability and autonomous operation needed for mission-critical remote deployments.
Key Features
- 720W peak power capacity with 157W continuous output rating
- High-capacity sealed lead-acid battery: 720Ah, 8640Wh total energy storage
- Integrated 7-port GigE 802.3at/passive PoE switch for network equipment
- Dual voltage output: 24V/48V selectable configuration
- 200W regulated output for stable device operation
- 6-hour peak sun autonomy for extended off-grid runtime
- Outdoor-rated enclosure for harsh environment deployment
- Complete system integration: solar input, battery, inverter, and switch in one unit
Technical Specifications
| Specification |
Value |
| Manufacturer |
TYCON SYSTEMS |
| Part Number |
RPAL48-720-720 |
| System Type |
Remote Power System with Integrated PoE Switch |
| Peak Power Rating |
720W |
| Continuous Output |
157W |
| Regulated Output |
200W |
| Battery Type |
Sealed Lead-Acid |
| Battery Capacity |
720Ah |
| Total Energy Storage |
8640Wh |
| Output Voltage Options |
24V / 48V selectable |
| PoE Switch Ports |
7-port GigE 802.3at/passive PoE |
| Peak Sun Autonomy |
6 hours |
| Deployment Type |
Outdoor off-grid installation |
Frequently Asked Questions
What is the RemotePro RPAL48-720-720 used for?
The RemotePro is a remote power system designed for off-grid network deployments. It powers remote base stations, wireless access points, surveillance systems, and distributed network equipment in locations without reliable grid power, providing autonomous operation with integrated PoE switching.
How long does the battery provide power during peak sun conditions?
The system delivers 6 hours of autonomy at peak sun conditions with its 8640Wh sealed lead-acid battery storage, ensuring continuous operation of connected network devices even during extended cloudy periods or overnight operation.
Can the RemotePro power multiple network devices simultaneously?
Yes. The integrated 7-port GigE 802.3at/passive PoE switch allows you to connect and power up to 7 network devices simultaneously, making it ideal for distributed remote installations requiring multiple powered endpoints.
What voltage configurations does this remote power solution support?
The RemotePro RPAL48-720-720 offers selectable 24V or 48V output, providing flexibility to match your specific network equipment requirements and optimize power distribution efficiency for your remote deployment.
