Tycon RemotePro RPAL24/48M-14-1440 Off-Grid Solar Power System
The RemotePro 1440+W Series is a complete off-grid power system engineered for remote telecommunications, surveillance, and autonomous applications requiring reliable, long-duration energy storage. With 1440W of solar capacity and 1440Ah SLA battery storage totaling 17280Wh, this system delivers continuous 24/48V 30A output for mission-critical remote installations. Perfect for cell tower backup, remote monitoring stations, and off-grid facilities where grid power is unavailable or unreliable.
Key Features
-
1440W Solar Array Input — Maximum solar generation capacity for rapid battery charging in daylight hours
-
1440Ah SLA Battery Bank — 17280Wh total energy storage for extended autonomous operation
-
315W Continuous Output — Stable 24/48V 30A power delivery for sensitive remote equipment
-
Dual Voltage Configuration — Selectable 24V or 48V output for flexible system integration
-
Sealed Lead Acid Technology — Maintenance-free, weather-resistant battery chemistry
-
Outdoor-Rated Enclosure — Ruggedized design for harsh remote environments
-
Long-Duration Autonomy — Multi-day operation capability without solar input
-
Integrated Charge Controller — Optimized MPPT solar charging management
Technical Specifications
| Specification |
Value |
| Manufacturer |
Tycon Systems |
| Model Number |
RPAL24/48M-14-1440 |
| Product Series |
RemotePro 1440+W |
| Solar Input Capacity |
1440W |
| Battery Capacity |
1440Ah SLA |
| Total Energy Storage |
17280Wh |
| Output Voltage |
24V / 48V (Selectable) |
| Continuous Output Current |
30A |
| Continuous Power Output |
315W |
| Battery Type |
Sealed Lead Acid (SLA) |
| Application |
Off-Grid Remote Power |
| Typical Use Cases |
Telecommunications, Surveillance, Remote Monitoring |
Frequently Asked Questions
What is an off-grid power system and how does the RemotePro work?
An off-grid power system operates independently from utility power, using solar panels and battery storage to generate and store energy. The RemotePro RPAL24/48M-14-1440 captures sunlight through its 1440W solar array, charges the 1440Ah battery bank, and delivers steady 24/48V power to remote equipment without grid dependency.
How long can the 1440Ah SLA battery power remote equipment?
Runtime depends on your load consumption. With the 315W continuous output capacity and 17280Wh total storage, a 100W load can run approximately 172 hours (7+ days) on battery alone. The integrated solar charging extends autonomy indefinitely during daylight operation.
Can I choose between 24V and 48V output for my remote installation?
Yes. The RemotePro RPAL24/48M-14-1440 features selectable dual voltage output (24V or 48V), allowing you to match your remote equipment's power requirements without additional converters or adapters.
Is the 1440W solar capacity sufficient for continuous remote operation?
The 1440W solar input is designed to fully recharge the 1440Ah battery during peak daylight hours, enabling continuous 24/7 operation in most climates. Actual charging speed depends on sunlight availability, season, and geographic location.
