Tycon Power PoE Injector
Description
The TP-POE-1824 is a unique Power Over Ethernet adapter which converts an 802.3af/at 48VDC POE input into a 18V or 24VDC regulated passive POE output. The POE output voltage is external jumper selectable and capable of up to 25W power output. The POE input is IEEE 802.3af/at compatible so the TP-POE-1824 will work with standard 802.3af/at compliant POE switches or routers. The TP-POE-1824 enables the powering of passive POE devices from standard 802.3af/at POE switches, which eliminates the extra expenses usually required to power non compliant equipment.
There are two models available:
TP-POE-1824 which is 10/100MB compatible and has a 12W output.
TP-POE-1824G which is 10/100/1000MB compatible and has a 24W output.
They accept data-in and 802.3af/at POE to a shielded RJ45 Jack and provide data-out and 18V or 24V POE on the shielded RJ45 output jack. They workby supplying power to the remote device on the unused Ethernet pins 4,5(V+) and 7,8(V-). The Ethernet spec supports distances up to 100m (328 feet).
They have various protections for surge, short circuit, overload and overvoltage.
Product Type: PoE Injector
Environmentally Friendly: Yes
Certifications & Standards:
- FCC Class B
- NE55022 Class B
- UL1950
- CSA 22.2
- TUV EN60950
TV
Brand Name: Tycon Power
Compatibility:
- Wireless Access Points
- Client Devices
- IP Phone
- Security Camera Systems
Form Factor: External
Length: 3.3"
Manufacturer: Tycon Power Systems
Product Name: PoE Injector
Mount Type: Floor/Desktop/Wall-mountable
Manufacturer Part Number: TP-POE-1824G
Manufacturer Website Address: http://www.tyconpower.com
Limited Warranty: 1 Year
Weight (Approximate): 5.29 oz
