The SmartOnline 750VA UPS is ideal for IT managers and organizations needing robust power protection for data centers and network environments. Its double-conversion technology provides continuous power conditioning by converting AC input to DC and back to AC, ensuring consistent, reliable output.
-
Double-Conversion Technology: Offers superior protection against power fluctuations, providing zero transfer time to prevent equipment shutdowns.
-
2U Rack/Tower Design: Accommodates both rackmount installation and standalone setups, providing flexible deployment options.
-
Extended Runtime: External battery packs are supported for enhancing uptime during power outages.
-
Interactive LCD: Delivers real-time status updates on power conditions, battery status, and load levels.
-
Multi-Connection Capabilities: Includes USB and DB9 serial connectivity, with optional network management card for remote access.
Technical Specifications
| Manufacturer |
Tripp Lite by Eaton |
| Model Number |
SU750RTXLCD2U |
| Type |
Double-Conversion UPS |
| Capacity |
750VA / 675W |
| Input Voltage |
120V AC |
| Output Waveform |
Pure Sine Wave |
| Form Factor |
2U Rack/Tower |
| Topology |
True Double-Conversion |
| Display |
Interactive LCD with power data |
| Outlets |
8 NEMA 5-15R outlets |
| Management |
USB, DB9 Serial, Optional Network Card |
| Battery |
Hot-swappable with extended runtime capability |
Frequently Asked Questions
Q: What are the benefits of double-conversion technology in this UPS?
A: The double conversion UPS provides superior power protection by continuously converting incoming AC power to DC, then back to clean AC power. This ensures zero transfer time during power outages, making it ideal for sensitive electronic equipment.
Q: Why is sine wave output important for my equipment?
A: Sine wave output delivers clean, utility-grade power that sensitive electronics need for optimal performance, reducing risks of damage or data loss.
Q: Can this UPS be used in both rack and tower configurations?
A: Yes, it is designed to be versatile, allowing for either a rackmount setup in a standard server rack or standalone tower operation.
Q: What extended run options are available for longer backup times?
A: It supports external battery packs to extend backup duration, adapting to the critical needs of enterprise applications.
Q: What LCD and management features does this UPS include?
A: The unit features an LCD for real-time monitoring, USB and DB9 for system integration, and optional network management for remote supervision.
