Tripp Lite N286-01Glx-Slx Hp J4859C Compatible Sfp Transceiver, 1000Base-Lx, Ddm, Singlemode Lc, 1310 Nm, 10 Km

HP J4859C Compatible SFP Transceiver, 1000Base-LX, DDM, Singlemode LC, 1310 nm, 10 km

Tripp Lite N286-01GLX-SLX HP J4859C Compatible SFP Transceiver, 1000Base-LX, DDM, Singlemode LC, 1310 nm, 10 km. SFP transceiver type: Fiber optic, Maximum data transfer rate: 10000 Mbit/s, Interface type: SFP+. Product colour: Metallic, Country of origin: China. Width: 13.2 mm, Depth: 56.9 mm, Height: 8.4 mm. Number of products included: 1 pc(s), Package width: 114 mm, Package depth: 45 mm. Master (outer) case width: 230.1 mm, Master (outer) case length: 130 mm, Master (outer) case height: 59.9 mm

The N286-01GLX-SLX HP J4859C Compatible 1000Base-LX LC SFP Transceiver with a duplex LC female connector functions just like the HP J4859C transceiver module and is designed to operate with HP networking equipment. It also meets or exceeds the J4859C’s original specifications and complies with MSA (Multi-Source Agreement) standards.

This 1000Base-LX transceiver is fully hot-pluggable, so you can install it without shutting down the network or rebooting your device. It supports data transfer rates up to 1 Gbps with 1310 nm wavelength signaling. It transmits across six miles (10 kilometers) of 9/125 SMF cabling.

The N286-01GLX-SLX also supports DDM, so you can monitor optical output power, optical input power, temperature, laser bias current and transceiver supply voltage. It is electrical interface-compliant with SFF-8431 specification.

1000Base-LX Transceiver with Duplex LC Connector
Hot-pluggable for installation without rebooting or shutting down
Data transfer rates up to 1 Gbps
Transmits up to 6 miles (10 km) with 9/125 SMF cabling
Supports DDM
Electrical interface-compliant with SFF-8431 specification
1310 nm wavelength signaling

Designed for Use with HP Networking Equipment
Functionally equivalent to HP J4859C
Meets or exceeds J4859C specs
Complies with MSA standards
