This Gigabit singlemode fiber solution is perfect for enterprise WAN connections, campus networks, and long-distance installations requiring reliable poe power over ethernet adapter functionality with extended reach capabilities. Our Tripp Lite N785-P01-SC-SM1 delivers:
-
Singlemode fiber transmission enabling 20km distance capability for long-range network extensions
-
Ethernet media converter functionality bridging fiber infrastructure with copper PoE+ requirements
-
PoE+ power delivery providing up to 30 watts for remote wireless access points and IP cameras
-
SC connectors offering secure and industry-standard fiber optic connections
Key Features
-
20km transmission range over singlemode fiber enabling building-to-building connections
-
PoE+ power injection delivering IEEE 802.3at compliant power for high-performance devices
- Optimized for fiber ethernet switches integration with seamless power and data delivery
- Consistent 1310nm wavelength operation ensuring reliable long-distance transmission
-
Auto-negotiating gigabit speeds supporting 10/100/1000 Mbps ethernet connections
- Compatible with network switch fiber optic infrastructure and IP surveillance systems
Technical Specifications
| Manufacturer |
Tripp Lite by Eaton |
| Model Number |
N785-P01-SC-SM1 |
| Product Type |
Gigabit Singlemode Fiber Ethernet Media Converter |
| Ethernet Port |
1 x 10/100/1000Base-T RJ-45 with PoE+ |
| Fiber Port |
1 x SC connector singlemode |
| Fiber Type |
Singlemode (SMF) 9/125μm |
| Wavelength |
1310nm |
| Maximum Distance |
Up to 20km (12.4 miles) |
| Data Rates |
10/100/1000 Mbps auto-negotiating |
| PoE Standard |
IEEE 802.3at PoE+ (up to 30W) |
| Power Budget |
-3dBm to -23dBm optical power |
| Receiver Sensitivity |
-23dBm minimum at 1310nm |
| Operating Temperature |
0°C to 70°C (32°F to 158°F) |
| Storage Temperature |
-40°C to 85°C (-40°F to 185°F) |
| Humidity |
5% to 95% non-condensing |
| LED Indicators |
Power, Link/Act, Speed, PoE, Fiber Link |
| Standards Compliance |
IEEE 802.3, 802.3u, 802.3ab, 802.3at |
| Mounting |
Desktop or DIN rail mounting options |
| Power Supply |
External power adapter (included) |
| Warranty |
3-year manufacturer warranty |
Frequently Asked Questions
Q: What is the maximum transmission distance for this converter?
A: This singlemode fiber converter supports transmission distances up to 20km (12.4 miles) using standard SMF cable, making it ideal for campus networks, building-to-building connections, and metropolitan area networks requiring long-distance connectivity.
Q: What devices can be powered through the PoE+ functionality?
A: The PoE+ capability delivers up to 30 watts, powering high-performance wireless access points, PTZ IP cameras, VoIP phones, LED lighting systems, and other IEEE 802.3at compliant devices over the extended fiber connection.
Q: How does this benefit long-distance IP camera installations?
A: This ethernet media converter enables IP camera deployments beyond traditional copper limitations while providing PoE+ power, perfect for perimeter security, parking structure monitoring, and remote facility surveillance applications requiring 20km reach.
Q: What type of fiber connectors are used?
A: The converter features industry-standard SC connectors for singlemode fiber, providing secure and reliable connections compatible with existing fiber infrastructure, patch panels, and enterprise networking equipment.
Q: Is this suitable for enterprise WAN connections?
A: Yes, this gigabit converter is ideal for enterprise WAN applications, campus backbone connections, and metropolitan area networks requiring reliable long-distance data transmission with PoE+ power delivery for remote network equipment and security devices.
Gigabit singlemode fiber Ethernet media converter PoE+ SC 20km by Tripp Lite. Long-distance fiber to ethernet conversion with power over ethernet for enterprise networks.
