This media converter is perfect for enterprise networks, IP security systems, and wireless access point installations requiring reliable power over ethernet adapter functionality with fiber connectivity. Our Tripp Lite N785-P01-SC-MM2 delivers:
-
PoE+ power delivery providing up to 30 watts for high-power devices over fiber connections
-
Multimode fiber connectivity extending network reach up to 2km with SC connector interface
-
Gigabit Ethernet performance ensuring full-speed data transmission and PoE power delivery
-
Professional grade construction built for mission-critical network infrastructure applications
Key Features
-
PoE+ power injection delivering 30W power over ethernet for wireless APs and IP cameras
-
2km transmission range over multimode fiber enabling long-distance network extensions
- Optimized for fiber ethernet switches integration with seamless PoE power delivery
- Consistent gigabit performance maintaining 10/100/1000 Mbps auto-negotiation
-
SC connector design providing secure and reliable multimode fiber connections
- Compatible with network switch fiber optic installations and IP surveillance systems
Technical Specifications
| Manufacturer |
Tripp Lite by Eaton |
| Model Number |
N785-P01-SC-MM2 |
| Product Type |
PoE+ Multimode Fiber Media Converter |
| Ethernet Port |
1 x 10/100/1000Base-T RJ-45 with PoE+ |
| Fiber Port |
1 x SC connector multimode |
| Fiber Type |
Multimode (MMF) 62.5/125μm or 50/125μm |
| Wavelength |
1310nm |
| Maximum Distance |
Up to 2km (1.2 miles) |
| Data Rates |
10/100/1000 Mbps auto-negotiating |
| PoE Standard |
IEEE 802.3at PoE+ (up to 30W) |
| Power Consumption |
PoE+ pass-through + converter operation |
| Operating Temperature |
0°C to 50°C (32°F to 122°F) |
| Humidity |
5% to 90% non-condensing |
| LED Indicators |
Power, Link/Act, Speed, PoE status |
| Standards Compliance |
IEEE 802.3, 802.3u, 802.3ab, 802.3at |
| Mounting |
Desktop or DIN rail mounting |
| Power Supply |
External power adapter (included) |
| Warranty |
3-year manufacturer warranty |
Frequently Asked Questions
Q: What devices can be powered through this PoE+ media converter?
A: This PoE+ converter delivers up to 30 watts, powering high-performance wireless access points, PTZ IP cameras, LED lighting systems, and other IEEE 802.3at compatible devices over extended fiber connections.
Q: What is the maximum transmission distance for this converter?
A: The converter supports up to 2km transmission distance over multimode fiber using standard MMF cable with 1310nm wavelength, ideal for campus networks and building-to-building connections.
Q: How does this benefit IP security camera installations?
A: This ethernet to fiber converter enables IP camera installations beyond copper cable limitations while providing PoE+ power, perfect for perimeter security, parking lot surveillance, and remote location monitoring systems.
Q: What type of fiber connector does this use?
A: The converter features standard SC connector interfaces for multimode fiber, providing secure connections compatible with existing fiber infrastructure and patch panels.
Q: Is this suitable for wireless access point deployments?
A: Yes, this power over ethernet adapter is ideal for extending wireless networks over fiber while providing PoE+ power for high-performance access points in locations where copper cabling is impractical or insufficient.
Media converter PoE+ multimode fiber Gigabit Ethernet SC 2km by Tripp Lite. Power over ethernet adapter with fiber connectivity for IP cameras and wireless APs.
