External 48V 4U Battery Pack for select UPS Systems (BP48V48RT4U)
Tripp Lite BP48V48RT4U External 48V 4U Battery Pack for select UPS Systems (BP48V48RT4U). Battery voltage: 48 V, Product colour: Black, Battery life: 6 year(s). Weight: 65 kg, Width: 440.2 mm, Height: 175 mm. Package width: 571.5 mm, Package height: 342.9 mm, Package depth: 596.9 mm. Master (outer) case width: 571.5 mm, Master (outer) case length: 596.9 mm, Master (outer) case height: 342.9 mm
BP48V48RT4U - 4u external battery pack offers extended battery runtime when used in conjunction with expandable 48V Tripp Lite rackmount and tower UPS systems. 4u reduced-depth configuration with included 2 post mounting accessories is ideal for use with Tripp Lite Compact Rackmount models SMART2200CRMXL and SMART3000CRMXL. Includes heavy gauge cabling with high current DC connector for safe, simple installation. Included daisychain connector enables the connection of additional compatible 48V external battery packs to the host UPS. Included mounting accessories support 4U balanced 2 point center-mounting rackmount installation in 2 post racks. Options for 4 post mounting available.
Compatible with these UPS Systems - SMART2200CRMXL, SMART3000CRMXL, and other Tripp Lite UPS systems that specify the use of this battery pack. (Note: BP48V48RT4U, SMART2200CRMXL and SMART3000CRMXL include hardware for 2-post rackmount installation; most other rackmount UPS systems and battery packs include hardware for 4-post rackmount installation.)
Offers extended-run UPS operation when used in conjunction with compatible 48V DC Tripp Lite UPS systems Reduced-depth configuration is ideal for use with Tripp Lite Compact Rackmount UPS systems SMART2200CRMXL and SMART3000CRMXL Includes heavy gauge cabling with high current DC connectors for simple installation Daisychain connector enables the connection of additional compatible 48V external battery packs to the host UPS Included mounting brackets support rackmount installation in 4 post racks using only 4 rack spaces (4U) 4POSTRAILKIT option supports 4 post rackmount installation
General Information
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
BP48V48RT4U
Manufacturer Website Address
https://tripplite.eaton.com/
Brand Name
Tripp Lite by Eaton
Product Model
BP48V48RT4U
Product Name
BP48V48RT4U UPS External Battery Pack
Product Type
External Battery Pack
UPC
037332142474
Height
6.9"
Width
17.3"
Depth
16.7"
Weight (Approximate)
143.30 lb
Miscellaneous
Package Contents
BP48V48RT4U UPS External Battery Pack
BP48V48RT4U External Battery Pack
2-Post Rackmount Hardware
Owner's Manual with Warranty Information
Warranty
Limited Warranty
2 Year
