This Tripp Lite 8-Port KVM Switch Console with DisplayPort is perfect for IT administrators and data center professionals who need efficient server management from a single workstation. Our solution delivers:
-
8 port KVM switch with cables that controls multiple servers from one console
-
17-inch LCD display for clear visibility and space-efficient operation
-
DisplayPort connectivity optimization ensuring high-resolution video quality
-
Rack mount design for seamless data center integration
Key Features
-
8-port KVM switching to control up to 8 servers or computers
-
17-inch LCD monitor with 1280x1024 resolution
-
DisplayPort video input for superior digital video quality
-
1U rack mountable design for space-efficient installation
-
USB keyboard and mouse ports for peripheral connectivity
-
Hot-key switching for quick server selection
-
Auto-scan functionality for monitoring multiple systems
-
Password security for unauthorized access protection
Technical Specifications
| Manufacturer |
Tripp Lite |
| Model Number |
8-Port KVM Console DisplayPort |
| Type |
8-Port KVM Switch Console with LCD |
| Number of Ports |
8 ports |
| Display |
17-inch TFT LCD |
| Resolution |
1280 x 1024 @ 75Hz |
| Video Input |
DisplayPort 1.2 |
| Keyboard/Mouse |
USB 2.0 |
| Switching Method |
Hot-key, push button, auto-scan |
| Hot-key Commands |
Scroll Lock + Scroll Lock + Port# |
| Auto-scan Interval |
5-99 seconds (user selectable) |
| Security |
Password protection, user access control |
| Form Factor |
1U rack mountable with sliding rails |
| Power Requirements |
100-240V AC, 50/60Hz |
| Power Consumption |
Maximum 35W |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Humidity |
10% to 80% non-condensing |
| Dimensions |
17.3" x 1.7" x 24.8" (WxHxD) |
| Weight |
Approximately 28 lbs (12.7 kg) |
| Compatible Systems |
Servers with DisplayPort, workstations, data center equipment |
Frequently Asked Questions
Q: What makes this KVM console ideal for data center environments?
A: This Tripp Lite 8-port KVM switch console combines a 17-inch LCD display with DisplayPort connectivity in a space-saving 1U rack mount design, allowing data center administrators to control up to 8 servers from a single console while maximizing server rack space efficiency.
Q: How does DisplayPort connectivity benefit server management?
A: DisplayPort video input provides superior digital video quality with support for high resolutions, ensuring crisp, clear display output for precise server administration tasks and reducing eye strain during extended data center management sessions.
Q: What switching options are available for server selection?
A: The 8 port KVM switch offers multiple switching methods including hot-key commands (Scroll Lock sequences), front panel push buttons, and auto-scan functionality with user-selectable intervals from 5-99 seconds for continuous monitoring of connected systems.
Q: How does the rack mount design benefit server room installations?
A: The 1U rack mountable design with sliding rails allows the console to be installed in standard 19-inch server racks, providing convenient access when needed while conserving valuable rack space when the console is not in active use.
Q: What security features protect server access?
A: The console includes password protection and user access control features, ensuring that only authorized personnel can access connected servers and preventing unauthorized modifications to critical server systems.
Q: Is this console suitable for managing different server types?
A: Yes, this KVM console DisplayPort is compatible with any server or workstation equipped with DisplayPort output and USB ports, making it ideal for managing mixed server environments including Dell, HP, IBM, and other enterprise rack mount servers.
Tripp Lite 8-Port KVM Switch Console with DisplayPort and 17-inch LCD for efficient data center server management and rack mount installation.
