3 Breaker Maintenance Bypass Panel for select Tripp Lite 20 and 30kVA UPS systems
Tripp Lite 3 Breaker Maintenance Bypass Panel. Product type: Bypass switch, Mounting type: Wall-mount. Input voltage: 120 - 208 V, Maximum total current draw per phase: 100 A. Width: 609.6 mm, Depth: 141.2 mm, Height: 304.8 mm. Products per master (outer) case: 1 pc(s), Master (outer) case width: 368.3 mm, Master (outer) case length: 673.1 mm
Wallmount 3 breaker manual bypass panel with mechanical interlock system isolates the UPS from connected loads for maintenance with no loss of network availability. 100A breaker with KAIC rating of 10. Compatible with Tripp Lite SU20K3/3, SU20K3/3XR5, SU30K3/3 and SU30K3/3XR5.
- Wallmount 3 breaker manual bypass panel with mechanical interlock system - Isolates the UPS from connected loads for maintenance with no loss of network availability - 100A breaker with KAIC rating of 10 - Compatible with Tripp Lite SU20K3/3, SU20K3/3XR5, SU30K3/3, SU30K3/3XR5 and SV20K__ models.
General Information
Manufacturer
Tripp Lite by Eaton
Manufacturer Part Number
SU2030KMBP
Manufacturer Website Address
https://tripplite.eaton.com/
Brand Name
Tripp Lite by Eaton
Product Model
SU2030KMBP
Product Name
SU2030KMBP Bypass Panel
Product Type
Bypass Panel
UPC
37332181800
Height
12"
Width
24"
Depth
4.6"
Weight (Approximate)
27.50 lb
Environmentally Friendly
Yes
Warranty
Limited Warranty
1 Year
