Description
10/100/1000Base-T (RJ-45) to 1000Base-SX, multimode SC, [62.5/125 um: 220 m/722 ft.] [50/125 um: 550 m/1804 ft.] Link Budget: 7.5 dB
Transition Networks M/GE-ISW-SX-01. Networking standards: IEEE 802.3,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z, Ethernet LAN data rates: 10,1000 Mbit/s, Copper ethernet cabling technology: 10BASE-T,100BASE-T,1000BASE-T. Fiber optic connector: SC, Connectivity technology: Wired. Maximum transfer distance: 550 m, Fiber mode structure: Multi-mode, Fiber cable diameters supported (core/cladding): 50/125,62.5/125 µm. LED indicators: Activity, Link, Power, Status, Product colour: Black, Certification: FCC Class A, CISPR22/EN55022 Class A, EN55034, CE. Input voltage: 12 - 48 V, Power consumption (typical): 1.2 W
The M/GE-ISW-xx-01 is an hardened Gigabit Ethernet Mini media converter that provides a cost effective, entry-level media conversion between 10/100/1000Base-T ports and 1000Base-SX/LX ports for hardened or outdoor 10/100/1000 environments. With its supported operating temperature range of -40°C to +75°C, the Mini offers a space saving alternative for converting copper to fiber in extreme environments.
General Information
Manufacturer
Transition Networks, Inc
Manufacturer Part Number
M/GE-ISW-SX-01
Manufacturer Website Address
http://www.transition.com
Brand Name
Transition Networks
Product Model
M/GE-ISW-SX-01
Product Name
Hardened Mini 10/100/1000 Bridging Media Converter
Product Type
Transceiver/Media Converter
UPC
648177039975
Ethernet Technology
Gigabit Ethernet
Network (RJ-45)
Yes
Height
0.9"
Width
1.8"
Depth
3.3"
Weight (Approximate)
6.40 oz
Miscellaneous
Package Contents
Hardened Mini 10/100/1000 Bridging Media Converter
