Twisted Pair, RJ-11 to 1310nm, single mode, SC (Customer Side FXO)
Transition Networks CAPTF3314-115. Fiber optic connector: SC, Connectivity technology: Wired. Maximum transfer distance: 20000 m, Wavelength: 1310 nm, Fiber mode structure: Single-mode. Certification: FCC A, VCCI A, EN 55022 (CISPR 22) A, ICES 003, CISPR A, CE. Power consumption (typical): 7 W. Package weight: 450 g
Connect central-office voice grade signals to distant Plain Old Telephone equipment (POTS) utilizing standard telephone signaling. Two units are required to implement an end to end system. Unit A connects to a telephone line or PBX and has the ability to detect ringing voltages and to act as a telephone (LINE SIDE FXS). Unit B is the reciprocal unit and has the ability to act as a Central Office and connects to a telephone device (CUSTOMER SIDE FXO).
- Audio transmission - Caller ID - Automatic ring down - Dual or single fiber options - SNMP Management - Ringing at the distant end - Electrical interface is provided through an RJ-11 female connector - Field Upgradeable Firmware - 300 Hz - 3 kHz
General Information
Manufacturer
Transition Networks, Inc
Manufacturer Part Number
CAPTF3314-115
Manufacturer Website Address
http://www.transition.com
Brand Name
Transition Networks
Product Model
CAPTF3314-115
Product Name
Media Converter
Product Type
Transceiver/Media Converter
UPC
648177029754
Height
3.4"
Width
5"
Depth
1.8"
Warranty
Limited Warranty
Lifetime
