Taoglas MA1508 Synergy 8-in-1 Combination Antenna
The Taoglas MA1508 Synergy is a next-generation 8-in-1 combination antenna engineered for demanding vehicle roof applications requiring simultaneous GNSS positioning, 5G/4G cellular connectivity, and Wi-Fi coverage. This permanent mount antenna integrates multi-constellation GNSS, four 5G/4G MIMO cellular channels, and three Wi-Fi MIMO bands into a single IP67-rated waterproof enclosure. Ideal for fleet telematics, real-time video streaming, connected vehicle platforms, and IoT systems, the MA1508 delivers enterprise-grade reliability with robust PC housing and high-performance RF design.
Key Features
- 8-in-1 integrated antenna system: GNSS + 4×5G/4G MIMO + 3×Wi-Fi MIMO
- Multi-constellation GNSS support for global positioning accuracy
- Quad-channel 5G/4G cellular MIMO for enhanced signal strength and data throughput
- Triple-band Wi-Fi MIMO (2.4 GHz and 5.8 GHz) for dual-band connectivity
- IP67-rated waterproof enclosure for harsh outdoor environments
- Durable polycarbonate housing designed for vehicle roof permanent mounting
- High-performance RF design optimized for real-time video and infotainment streaming
- Compact single-unit form factor reduces installation complexity
- Supports advanced telematics, fleet management, and connected vehicle applications
Technical Specifications
| Specification |
Details |
| Manufacturer |
TAOGLAS USA INC. |
| Part Number |
MA1508.AK.006.PM |
| Product Type |
8-in-1 Combination Antenna |
| GNSS Support |
Multi-constellation positioning |
| Cellular Bands |
4×5G/4G MIMO channels |
| Wi-Fi Bands |
3×MIMO (2.4 GHz and 5.8 GHz) |
| Mounting Type |
Vehicle roof permanent mount |
| IP Rating |
IP67 (waterproof) |
| Housing Material |
Polycarbonate (PC) |
| Primary Applications |
Telematics, video streaming, infotainment, IoT connectivity |
Frequently Asked Questions
What is an 8-in-1 combination antenna used for?
An 8-in-1 combination antenna like the MA1508 consolidates multiple connectivity functions—GNSS positioning, 5G/4G cellular, and Wi-Fi—into a single unit. This reduces installation footprint, simplifies wiring, and provides seamless multi-band coverage for vehicles requiring simultaneous positioning and high-speed data connectivity for telematics, fleet tracking, and real-time video applications.
Can the Taoglas MA1508 handle 5G and 4G simultaneously?
Yes. The MA1508 features quad-channel 5G/4G MIMO architecture, enabling simultaneous operation across multiple 5G and 4G bands. This multi-channel design ensures robust cellular connectivity, improved signal strength, and higher data throughput—critical for demanding applications like live video streaming and low-latency telematics.
Is the MA1508 waterproof for outdoor vehicle mounting?
Absolutely. The antenna is IP67-rated, providing complete protection against dust and water immersion. Its durable polycarbonate housing and sealed design make it ideal for permanent roof mounting on vehicles exposed to rain, snow, and harsh environmental conditions.
What applications benefit most from this GNSS and 5G/4G antenna?
The MA1508 excels in fleet management, connected vehicle platforms, real-time video surveillance systems, IoT telematics, autonomous vehicle support, and infotainment systems. Any application requiring simultaneous GNSS positioning, 5G/4G connectivity, and Wi-Fi coverage benefits from this integrated solution.
