SuperServer 2029TP-HC1R (Black), 2U Rackmount, 16 DIMM slots, Dual Socket P (LGA 3647)
Supermicro SYS-2029TP-HC1R. Motherboard chipset: Intel® C621, Processor socket: LGA 3647 (Socket P). Supported memory types: DDR4-SDRAM. Storage drive sizes supported: 2.5". BIOS type: AMI, BIOS memory size: 32 Mbit. Chassis type: Rack (2U), Product colour: Black, LED indicators: Activity, Power
1. Dual socket P (LGA 3647) supports Intel® Xeon® Scalable Processors, Dual UPI up to 10.4GT/s
2. Up to 2TB ECC 3DS LRDIMM, up to DDR4-2666MHz; 16 DIMM slots
3. 2 PCI-E 3.0 x16 (LP) slots
4. Flexible Networking support via SIOM; Dedicated IPMI 2.0 LAN
5. 6 Hot-swap 2.5" SAS/SATA drive bays
6. Broadcom 3108 SAS3 controller;
RAID 0, 1, 5, 6, 10, 50, 60 with
SuperCap option
7. Up to 2200W Redundant Power Supplies
Titanium Level (96%
