SuperServer Benefits: - Uncompromising Quality Control - The most Comprehensive Line of Servers, Storage Systems, and Subsystems - Widest Variety of Application Optimized Solutions, from High End Clusters to MicroServers - Best Performance per-Watt, per-Square-Foot, and per-Dollar - Superior Product Design Based in Silicon Valley - Consistently First-to-Market - Best Total Cost of Ownership (TCO) - Highest Quality Components and Materials - 3-Year Limited Warranty - 24-Hour Support and Global Services - Redfish API support
These benefits combined with an excellent track record have earned Supermicro a reputation as a true leader in the high-end server/storage industry. Supermicro provides the most outstanding product line in the industry, ranging from single Atom™ and dual Xeon® to quad Xeon® MP systems. Their proven high level of quality and performance has made SuperServers the platform of choice for HPC, enterprise, cloud, data center, hyperscale, embedded, and business-critical, front-end server applications.
General Information
Manufacturer
Supermicro Computer, Inc
Manufacturer Part Number
SYS-5019C-WR
Manufacturer Website Address
http://www.supermicro.com
Brand Name
Supermicro
Product Line
SuperServer
Product Model
5019C-WR
Product Name
SuperServer 5019C-WR (Black)
Product Type
Barebone System
UPC
0672042326105
Chipset
Chipset Manufacturer
Intel
Graphics Controller Manufacturer
ASPEED
Graphics Controller Model
AST2500
Ethernet Technology
Gigabit Ethernet
Total Number of USB Ports
4
Power Description
Maximum Power Supply Wattage
500 W
Product Color
Black
Height
1.7"
Width
17.2"
Depth
25.6"
Weight (Approximate)
25 lb
Miscellaneous
Package Contents
SuperServer 5019C-WR (Black)
1 x Super X11SCW-F Motherboard
1 x 1U Chassis
1 x 1U 4-Port 12Gbps Backplane Support 4x3.5
1 x 4 pin to 4 pin fan extension cord, for PWM fan. 23cm. 24AWG
2 x SATA,INT,ROUND,ST-RA,55CM,30AWG
1 x SATA,INT,ROUND,ST-RA,70CM,30AWG
1 x CBL,SGPIO,2X4F TO 2X4F,P2.54,ROUND CABLE,27CM,28AWG
1 x SATA,INT,ROUND,ST-RA,45CM,30AWG
2 x 40x40x56 mm 13K-11K RPM Counter-rotating Fan,RoHS/REACH
1 x SC815/113/116 Intel DP X9, X8 PC air shroud, 12x13MB
1 x 5019C-WR Quick Reference Guide
1 x 1U RHS WIO Riser card with one PCI-E x8 slot
1 x 1U LHS WIO w/ 2 PCI-E x8 slots or PCI-E x16 slot
1 x 1U Passive Enhanced Performance CPU Heat Sink for Intel Socket H Series Processors
2 x 500W 1U Redundant PWS W/ 54.5MM Wide
1 x WIO X11 Support,PDB-PT112-S2424 is based on PDB-PT112-2424
1 x CBL,FRONT CNTL,20 TO 20 PIN,RA,RND TUBE,73CM,28AWG
2 x PWCD,US,NEMA5-15P TO IEC60320 C13,6FT,16AWG,13A,125V,RoHS/REACH
1 x FAN HOLDER FOR SIX 40X56MM COUNTER ROTATING FANS
1 x Black DVD dummy cover for SC813, 813M, 815, PBF-RoHS
3 x 40x40x56 mm 13K-11K RPM Counter-rotating Fan,RoHS/REACH
1 x 815 UIO front control board (U)
1 x Blank LP L-bracket (1 raw of capsule hole)
2 x Blank FH L bracket w/o SCSI cutout for SC825,836,846,743
4 x Black gen 5.5 hot-swap 3.5"; HDD tray
1 x WIO rear window for SC113,SC116, SC815 Redundant PWS
1 x SC815 Redundant Power Distributor Cover
1set x Rail set, quick/quick, optional for 1U 17.2
3 x Dummy fan 40x56mm for 40x56 counter-rotating fan (cost-effective)
