Dual Socket P (LGA 3647), 8x DIMM DDR4, Intel C621, 8x SATAIII, 2x RJ-45, IPMI LAN, 2x USB 2.0, VGA, 1U, 437x43x508 mm
Supermicro SuperServer 1029P-MTR. Motherboard chipset: Intel® C621, Processor socket: LGA 3647 (Socket P), System bus rate: 10.4 GT/s. Supported memory types: DDR4-SDRAM, Maximum internal memory: 1000 GB, Maximum RDIMM memory: 512 GB. Storage drive sizes supported: 2.5", Supported storage drive interfaces: Serial ATA III. On-board graphics adapter model: Aspeed AST2500. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, Copper ethernet cabling technology: 1000BASE-T
SuperServers are Your Best Choice!
SuperServer Benefits: - Uncompromising Quality Control - The most Comprehensive Line of Servers, Storage Systems, and Subsystems - Widest Variety of Application Optimized Solutions, from High End Clusters to MicroServers - Best Performance per-Watt, per-Square-Foot, and per-Dollar - Superior Product Design Based in Silicon Valley - Consistently First-to-Market - Best Total Cost of Ownership (TCO) - Highest Quality Components and Materials - 3-Year Limited Warranty - 24-Hour Support and Global Services - Redfish API support These benefits combined with an excellent track record have earned Supermicro a reputation as a true leader in the high-end server/storage industry. Supermicro provides the most outstanding product line in the industry, ranging from single Atom and dual Xeon to quad Xeon MP systems. Their proven high level of quality and performance has made SuperServers the platform of choice for HPC, enterprise, cloud, data center, hyperscale, embedded, and business-critical, front-end server applications.
General Information
Manufacturer
Supermicro Computer, Inc
Manufacturer Part Number
SYS-1029P-MTR
Manufacturer Website Address
http://www.supermicro.com
Brand Name
Supermicro
Product Line
SuperServer
Product Model
1029P-MTR
Product Name
SuperServer 1029P-MTR (Black)
Product Type
Barebone System
UPC
0672042291298
Chipset
Chipset Manufacturer
Intel
Graphics Controller Manufacturer
ASPEED
Graphics Controller Model
AST2500
Ethernet Technology
Gigabit Ethernet
Total Number of USB Ports
2
Power Description
Maximum Power Supply Wattage
600 W
Product Color
Black
Height
1.7"
Width
17.2"
Depth
20"
Miscellaneous
Package Contents
SuperServer 1029P-MTR (Black)
1 x Super X11DPL-i Motherboard
1 x 1U Chassis
1 x 8-port 1U SAS3 12Gbps Hybrid backplane, support up to 6x 2.5-inch SAS3/SATA3 HDD/SSD and 2x SAS3/SATA3/NVMe Storage Devices
2 x MINI SAS HD-4 SATA,6G,INT,RF,Cross Over,55CM,55CM SB,30AWG
1 x 1U I/O Shield for X11DPL-i with EMI Gasket
1 x SC813M,SC113M, DP X9DRL-EF/ X9DRL-7F/ X10DRL-i, X9/X10 mylar air shroud, 12
1 x 1029P-MT/MTR Quick Reference Guide
1 x RSC-RR1U-E8
2 x 1U Passive Proprietary CPU Heat Sink for X11DPL Motherboard Equipped with a Square Retention Mechanism
2 x AC-DC 600W single output power supply Platinum Level, Redund
4 x 40x40x28 mm, 22.5K RPM, SC813MF Middle Cooling Fan,RoHS/REACH
