2U, 1x SP3, SoC, 8x DIMMs, 8x Hot-swap 3.5" SAS3/SATA3, 2x RJ45, Aspeed AST2500 BMC, 740W
Supermicro A+ Server 2013S-C0R. Motherboard chipset: Intel SoC, Processor socket: Socket SP3, Processor family: AMD. Supported memory types: DDR4-SDRAM, Supported DIMM module capacities: 4GB, 8GB, 16GB, 32GB, 64GB, 128MB, 256MB, Maximum internal memory: 2000 GB. Storage drive sizes supported: 3.5,M.2, Supported storage drive types: HDD & SSD. On-board graphics adapter model: Aspeed AST2500. Ethernet interface type: Fast Ethernet, Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s, LAN controller: Intel I210
- Single AMD EPYC™ 7001/7002 Series Processor (AMD EPYC 7002 series drop-in support requires board revision 2.x)
- 1TB Registered ECC DDR4 2666MHz SDRAM in 8 DIMMs 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs (Board revision 2.x required)
- Expansion slots: 3 PCI-E 3.0 x16 (low profile); 3 PCI-E 3.0 x8 (low profile) M.2 Interface: PCI-E 3.0 x4 (NVMe based) M.2 Form Factor: 2280, 22110 M.2 Key: Onboard M-key Number of M.2: Single
- Integrated IPMI 2.0 + KVM with dedicated LAN
- 2x 1GbE LAN ports via Intel® I210
- 8 hot-swap 3.5" SAS3/SATA3 Drive Bays (on-board Broadcom 3008 IR mode),1 M.2 NVMe SSD slot Supported
- 740W Redundant Platinum Level Power Supplies
