Cisco C220 M5 1U Rack Server - 2 x Intel Xeon Gold 5120 2.20 GHz - 96 GB RAM - 12Gb/s SAS Controller
The UCS C220 M5 SFF server extends the capabilities of Cisco's Unified Computing System portfolio in a 1U form factor with the addition of the Intel® Xeon® Processor Scalable Family, 24 DIMM slots for 2666MHz DIMMs and up to 128GB capacities, two 2 PCI Express (PCIe) 3.0 slots, and up to 10 SAS/SATA hard disk drives (HDDs) or solid state drives (SSDs). The C220 M5 SFF server also includes one dedicated internal slot for a 12G SAS storage controller card.
The C220 M5 server included one dedicated internal modular LAN on motherboard (mLOM) slot for installation of a Cisco Virtual Interface Card (VIC) or third-party network interface card (NIC), without consuming a PCI slot, in addition to 2 x 10Gbase-T Intel x550 embedded (on the motherboard) LOM ports.
The Cisco UCS C220 M5 server can be used standalone, or as part of the Cisco Unified Computing System, which unifies computing, networking, management, virtualization, and storage access into a single integrated architecture enabling end-to-end server visibility, management, and control in both bare metal and virtualized environments.
- 40 Gigabit Ethernet for efficient data transfer and fast connectivity
- RAID provides data reliability, fault tolerance and improves overall performance
- With 96 GB memory, improve system performance to execute complex applications
- 2 x 770 W power supply unit (PSU) included
Product Type: Server
Product Series: C220 M5
Rack Height: 1U
Brand Name: Cisco
Form Factor: Rack
Manufacturer: Cisco Systems, Inc
Product Name: UCS C220 M5 Server
Manufacturer Part Number: UCS-SP-C220M5-A3
Manufacturer Website Address: http://www.cisco.com
Limited Warranty: 3 Year
Weight (Approximate): 37.50 lb
