SmartAVI SM-MST-4D KVM Switchbox
The SM-MST-4D converts a single DisplayPort 1.2 input signal to two separate HDMI Output connections through advanced MultiStream Transport technology. This allows a user to extend their display and achieve resolutions of up to 4K (3840 x 2160 @ 30 Hz) on each connected monitor from a single DP port.
The SM-MST-4D is a DisplayPort Standard Version 1.2a compliant device. The SM-MST-4D can control up to 4 computers with a single DP input connection each, and allows the support of two HDMI outputs in any combination.
- Supports Windows 7 and Windows 10
- Single-head DP to dual-head HDMI video interface for each connected computer
- Resolutions up to 4K UHD (3840 x 2160 @ 30Hz) per display
- DisplayPort1.2a dual mode receiver
- HDMI/DVI operation up to 320MHz
- Max video input resolution 4K2K@60Hz
- Multi-Stream Transport supports up to 2 streams
- Supports RGB or YCbCr
- Supports balanced speakers output and switching
- Front panel tactile buttons with LED indicator
Product Type: KVM Switchbox
Environmentally Friendly: Yes
Environmental Certification: RoHS
Country Of Origin: United States
Brand Name: SmartAVI
Manufacturer: Smart Audio Video Innovation
Product Model: SM-MST-4D
Product Name: SM-MST-4D KVM Switchbox
Manufacturer Part Number: SM-MST-4D
Manufacturer Website Address: http://www.smartavi.com
Weight (Approximate): 4.20 lb
