This HDMI matrix is perfect for AV integrators, corporate facilities managers, and digital signage professionals who need powerful video wall solutions with advanced routing capabilities. Our Smart Audio Video Innovation 16×16 system delivers:
-
16×16 matrix switcher providing unlimited routing flexibility for digital signage systems and large-scale installations
-
Integrated video wall processing enabling seamless content distribution across multiple displays with scalable configurations
-
4K UHD support delivering crystal-clear imagery compatible with switch hdmi 4k requirements for modern displays
-
Professional-grade reliability designed for 24/7 operation in commercial environments and control room applications
Key Features
-
True matrix switching allowing any input to route to any or all outputs simultaneously for maximum flexibility
-
Built-in video wall controller supporting multi-display configurations without external processors
- Optimized for digital signage applications with EDID management and signal optimization
- Consistent 4K resolution support at 60Hz ensuring compatibility with latest display technologies
-
Web-based control interface providing remote management and configuration capabilities
-
Hot-swappable input/output cards enabling field serviceability and future expansion options
Technical Specifications
| Manufacturer |
Smart Audio Video Innovation |
| Model |
16×16 HDMI Matrix with Integrated Video Wall |
| Type |
Professional HDMI Matrix Switcher |
| Input/Output Configuration |
16 HDMI inputs, 16 HDMI outputs |
| Video Resolution |
4K UHD (3840×2160) @ 60Hz, 1080p, 720p |
| Video Wall Support |
Up to 4×4 display configuration per output zone |
| HDCP Support |
HDCP 2.2 compliant |
| Audio Support |
Embedded digital audio, analog audio breakout |
| Control Methods |
Web GUI, RS-232, TCP/IP, IR remote |
| EDID Management |
Advanced EDID learning and assignment |
| Power Consumption |
150W maximum (varies by configuration) |
| Operating Temperature |
0°C to 40°C (32°F to 104°F) |
| Compatible Applications |
Corporate AV, retail displays, control rooms, education |
Frequently Asked Questions
Q: How does the integrated video wall processing enhance installation efficiency?
A: The integrated video wall controller eliminates the need for separate processors, reducing equipment costs and complexity. This matrix switcher can create seamless displays across multiple screens with automatic bezel compensation and scaling, making it ideal for digital signage systems requiring professional presentation quality.
Q: What makes this matrix solution scalable for growing installations?
A: This scalable design supports modular expansion with hot-swappable I/O cards and cascading capabilities. The system can grow from simple point-to-point connections to complex video wall projector arrays, accommodating evolving requirements without complete system replacement.
Q: Can this handle 4K content reliably for commercial applications?
A: Yes, this HDMI matrix supports full 4K UHD at 60Hz with HDCP 2.2 compliance, ensuring compatibility with modern switch hdmi 4k sources and displays. The advanced signal processing maintains video quality even through complex routing scenarios typical in professional AV installations.
Q: How does EDID management benefit multi-display installations?
A: Advanced EDID management ensures source devices receive optimal display information, preventing resolution conflicts and compatibility issues. This is crucial for digital signage applications where content must display consistently across different monitor types and manufacturers in the same installation.
16x16 HDMI matrix with integrated video wall by Smart Audio Video Innovation. Scalable digital signage matrix switcher with 4K support.
