SmartAVI IR CAT5 Point-to-Point Extender
The HDC-IR range of products allow the extension of Infra Red control signals using single CAT5 UTp (category 5, unshielded twisted pair) cable. The HDC-IR is the first product for this application.
- Uses easy to install, inexpensive CAT5.
- Output reaches up to 1000 feet (300m).
- Sends IR and Power signals over CAT5
- High ground loop immunity.
- Video cable compensation (automatic).
- Sends Composite Video Stereo Audio, IR and Power signals over CAT5.
- Compatible with line level stereo audio signals.
- High ground loop immunity.
- Built-in lightning, power surge and transient protection.
- Remote units come with buffered outputs.
- Compact enclosure.
- Optional power supply for remote unit.
- Fully compliant with standard modulated IR and the latest IRDA.
- Fully transparent path for all products and data transfers.
- Bi-directional IR.
- Supports any IR Remote Control
Product Type: IR Kit
Country Of Origin: United States
Brand Name: SmartAVI
Manufacturer: Smart Audio Video Innovation
Product Model: HDCIR
Product Name: IR CAT5 Point-to-Point Extender
Manufacturer Part Number: HDC-IRS
Manufacturer Website Address: http://www.smartavi.com
Package Contents:
- HDC-IR-TX Transmitter
- HDC-IR-RX Receiver
- SM-EYE External IR Receiver
- SM-LED IR Emitter 6ft Single LED
- PS12VDC2A Power Supply
