Server Technology PRO1 Switched PDU 48DCWC-04-2X100-D0NB - Master - power control unit (rack-mountable) - -48 V - 9.6 kW - Ethernet 10/100, RS-232 - input: terminal block - output connectors: 4
-
Reliable power management
Designed to offer efficient control over power distribution, ensuring that critical systems operate smoothly and safely.
-
Versatile connectivity options
Equipped with RJ-12 connectors for management interfaces, allowing flexible integration and monitoring through Ethernet and RS-232.
-
Advanced remote management capabilities
Supports various remote management protocols including Telnet, SNMP v2c, and SSH-2, facilitating comprehensive oversight of power devices.
-
Enhanced circuit protection features
Includes fuse circuit protection to prevent overloads, enhancing safety for both equipment and operations.
-
Efficient power output
Provides consistent -48 V output with the capability of supporting up to 9.6 kW, allowing effective power delivery to connected systems.
The Server Technology -48VDC Switched PDU provides control of outlet power and per-outlet current measurement through the built-in Web and CLI interfaces as well as through SNMP. Temperature and humidity measurements can be provided via optional probes. The Switched "Master" PDU can be connected to a Switched "Link" PDU to extend the network access to the redundant or secondary power feed.
- Gain access to valuable data through connections including HTTP(S), SSH, Telnet, SNMP, (S)FTP, SMTP, Syslog, LDAP(S), RS-232 serial, and more
- Network access is ensured when power is lost to the Master unit with backup power provided by the primary link unit
- Star Multi-Linking provides the ability to link up to four power circuits using one IP address
- Meets the UL and IEC 60950-1 requirement for branch circuit protection through the use of user specified TPC fuses
