Server Technology PRO1 Smart PDU C1S24TB-5QAE2766 - Master - power distribution unit (rack-mountable) - AC 415 V - 34.5 kW - 3-phase WYE (star) - Ethernet 10/100, RS-232 - input: IEC 60309 3P+N+G - output connectors: 24 (12 x IEC 60320 C13, 12 x IEC 60320 Cx)
-
Hot-swap network card
Network access is ensured when power is lost to the master unit with backup power provided by the primary link unit.
-
Auto-flip current display
Easy-to-read LEDs display current per phase to help prevent overloads and simplify three-phase load balancing in high-density cabinets.
-
Temperature/humidity monitoring
Master units support two external T/H probes. Receive SNMP-based alerts and email notifications.
-
Alternating-phase outlets
3-phase power is wired in an alternating fashion per outlet for simplified load balancing, reduced cord lengths, and better airflow.
The Server Technology PRO1 Smart PDU provides local LED input current monitoring, allowing IT personnel to determine safe levels of loading on a per-phase basis while installing equipment into the rack/cabinet. The integral PIPS technology provides billing-grade accurate measurement of current, voltage, active power, apparent power, power factor, crest factor, and accumulated energy at the input.
- Hot-swap network card
- Auto-flip current display
- Temperature/humidity monitoring
- Alternating-phase outlets
