Mfr Part Number: SSP-250SUB
-
Features:
- SATA-ready
- Fully modular
- High efficiency and reliability
- Low ripple and noise
- Super low noise fan control
- Short circuit protection on all outputs
- Over voltage protection
- Over power protection
- Fanless Mode (up to 30 % system load)
-
Type: Flex ATX
-
Total Power: 250 W
-
Input:
-
Current: 100A max.
-
Frequency: 47 - 63 Hz
-
Power Factor Correction: 95% typical
-
Efficiency: >85%(at normal input voltage)
-
MTBF: >100,000 hours
-
Output: +3.3V @ 14A, +5V @ 17A, +12V1@12A, +12V2 @ 12A,-12V @ 0.8A, +5VSB @ 2A
-
Connector: Main Power -ATX 12V;Peripherals - SATA, HDD
-
Safety: CB, CUL, CCC, TUV
-
EMI/EMC: BSMI, CE, FCC, RCM
-
Dimension (WxLxH): 81.5 x 150.0 x 40.5mm
