Schneider Electric GVSBPSU10K20H Maintenance Bypass Panel
The Schneider Electric GVSBPSU10K20H maintenance bypass panel is engineered for IT infrastructure managers and facility technicians who need safe, uninterrupted power during UPS system maintenance. This single-unit bypass solution supports Galaxy VS and Easy UPS 3S systems rated 10-20kW at 400V, enabling you to isolate your UPS for servicing while maintaining continuous power delivery to critical loads. Wall-mounted design saves valuable data center floor space while providing reliable electrical isolation and bypass functionality that meets industry installation standards.
Key Features
- Safe maintenance bypass for Galaxy VS and Easy UPS 3S UPS systems
- Rated for 10-20kW single-unit installations at 400V
- Wall-mount configuration for space-efficient deployment
- Enables load isolation without power interruption during service
- Integrated electrical isolation and bypass switching
- Compatible with Schneider Electric UPS infrastructure
- Meets relevant electrical installation and safety requirements
Technical Specifications
| Specification |
Details |
| Manufacturer |
APC by Schneider Electric |
| Part Number |
GVSBPSU10K20H |
| Product Type |
Maintenance Bypass Panel |
| Compatible UPS Systems |
Galaxy VS, Easy UPS 3S |
| Power Rating |
10-20kW |
| Input Voltage |
400V |
| Configuration |
Single Unit, Wall-Mount |
| Primary Function |
Safe UPS isolation and bypass during maintenance |
Frequently Asked Questions
What is a maintenance bypass panel used for?
A maintenance bypass panel allows you to safely isolate your UPS system for repairs or replacement while maintaining uninterrupted power to connected equipment. The GVSBPSU10K20H enables technicians to perform service work on Galaxy VS and Easy UPS 3S systems without causing downtime to critical loads.
Is the GVSBPSU10K20H compatible with all Schneider Electric UPS models?
No, this maintenance bypass panel is specifically designed for Galaxy VS and Easy UPS 3S systems rated between 10-20kW at 400V. Always verify compatibility with your UPS model before installation to ensure proper operation and safety.
Can I wall-mount this bypass panel in a standard server room?
Yes, the wall-mount design of the GVSBPSU10K20H is ideal for space-constrained data centers and server rooms. The compact configuration integrates seamlessly with existing Schneider Electric UPS installations while maintaining safe electrical isolation during maintenance procedures.
What power capacity does this bypass panel support?
The GVSBPSU10K20H is rated for single-unit UPS installations from 10kW to 20kW at 400V input voltage, making it suitable for mid-range enterprise power protection requirements.
