Saleae Logic Pro 8 Black USB Logic Analyzer
The Logic Pro 8 Black is a second-generation USB logic analyzer designed for engineers and developers who need reliable mixed-signal analysis capabilities. This versatile analyzer records both digital and analog signals simultaneously, with each input dual-purposed for flexible signal capture. Whether you're debugging embedded systems, developing hardware, or troubleshooting complex electronics, the Logic Pro 8 delivers the precision and ease-of-use you need for professional-grade signal analysis.
Connect via USB to any PC and leverage the intuitive Saleae Logic software to capture, analyze, and decode signals in real-time. With high-speed sampling and multiple channels, this USB logic analyzer is the go-to tool for mixed-signal debugging workflows.
Key Features
- Dual-purpose analog and digital signal recording on each input
- High-speed sampling for accurate mixed-signal capture
- Multiple channels for comprehensive signal analysis
- USB connectivity for seamless PC integration
- Intuitive Saleae Logic software for real-time signal viewing and decoding
- Ideal for embedded debugging and hardware development
- Second-generation design with improved performance and reliability
- Flexible test and measurement workflows for professional engineers
Technical Specifications
| Specification |
Details |
| Manufacturer |
STRATEGIC SOURCING |
| Part Number |
SAL-00113 |
| Product Name |
Logic Pro 8 Black |
| Signal Types |
Digital and Analog |
| Connection |
USB |
| Analysis Type |
Mixed-Signal Analysis |
| Software |
Saleae Logic |
| Primary Use Cases |
Embedded Debugging, Hardware Development, Signal Analysis |
Frequently Asked Questions
What is a USB logic analyzer used for?
A USB logic analyzer like the Logic Pro 8 Black is used for capturing and analyzing digital and analog signals in embedded systems and hardware projects. It helps engineers debug communication protocols, verify signal timing, and troubleshoot hardware issues in real-time.
Can the Logic Pro 8 Black record both digital and analog signals?
Yes, the Logic Pro 8 Black features dual-purpose inputs that allow simultaneous recording of both digital and analog signals. This mixed-signal capability makes it ideal for comprehensive hardware analysis and debugging.
How do I use the Logic Pro 8 Black for embedded debugging?
Simply connect the Logic Pro 8 Black to your PC via USB, attach your signal probes to the circuits you want to analyze, and use the Saleae Logic software to capture and decode signals. The software provides real-time visualization and protocol decoding for efficient embedded debugging.
What makes mixed-signal analysis important for hardware development?
Mixed-signal analysis allows you to simultaneously observe digital logic states and analog voltage levels, which is critical for debugging complex circuits that combine both signal types. This comprehensive view helps identify timing issues, signal integrity problems, and protocol violations quickly.
