Saleae Logic Pro 16 - 16-Channel Logic Analyzer
The Saleae Logic Pro 16 is a professional-grade 16-channel logic analyzer designed for embedded systems engineers, firmware developers, and hardware technicians who need reliable digital signal capture and protocol analysis. This logic analyzer delivers real-time debugging capabilities with advanced triggering, making it essential for troubleshooting complex digital circuits, validating communication protocols, and accelerating development cycles. Whether you're analyzing I2C, SPI, UART, or custom digital signals, the Logic Pro 16 provides the precision and performance required for professional-level embedded systems work.
Key Features
- 16 independent digital input channels for simultaneous signal capture
- Advanced triggering and protocol decoding for I2C, SPI, UART, and custom protocols
- High-speed sampling with real-time data streaming to host computer
- Compact, portable design with USB connectivity for field and lab use
- Intuitive software interface with multi-channel waveform visualization
- Flexible voltage support for mixed-signal environments
- Deep memory buffer for extended capture sessions
- Export capabilities for documentation and analysis integration
Technical Specifications
| Specification |
Details |
| Manufacturer |
STRATEGIC SOURCING |
| Part Number |
SAL-00116 |
| Product Type |
16-Channel Logic Analyzer |
| Digital Channels |
16 independent inputs |
| Interface |
USB 2.0 High-Speed |
| Supported Protocols |
I2C, SPI, UART, CAN, and custom protocols |
| Memory Depth |
High-capacity buffer for extended captures |
| Triggering |
Advanced edge and pattern-based triggers |
| Software Compatibility |
Windows, macOS, Linux |
| Form Factor |
Portable desktop unit |
Frequently Asked Questions
What is a 16-channel logic analyzer used for?
A 16-channel logic analyzer captures and displays digital signals from multiple sources simultaneously, enabling engineers to debug embedded systems, verify protocol communication, validate circuit behavior, and troubleshoot timing issues in real-time.
How does the Saleae Logic Pro 16 compare to other logic analyzers?
The Saleae Logic Pro 16 combines professional-grade performance with user-friendly software, offering advanced protocol decoding, flexible triggering, and seamless integration with development workflows—making it ideal for both prototyping and production debugging.
Can I use this logic analyzer for protocol analysis?
Yes, the Logic Pro 16 includes built-in protocol decoders for I2C, SPI, UART, CAN, and other common communication standards, allowing you to decode and analyze protocol traffic directly within the software interface.
What software platforms are supported?
The Saleae Logic Pro 16 is compatible with Windows, macOS, and Linux, providing cross-platform flexibility for development teams using different operating systems.
