Ribbon SBC-SFPMM-10G SFP+ SR Transceiver
The SBC-SFPMM-10G is a 10 Gigabit SFP+ SR transceiver engineered for high-speed data center and enterprise network deployments requiring reliable 10GBASE-SR connectivity. This multimode fiber transceiver delivers 10G performance over distances up to 300 meters at 850nm wavelength, making it ideal for campus networks, data center interconnects, and short-to-medium range fiber links. Built for demanding environments, it operates reliably across 0°C to +70°C temperature ranges and integrates seamlessly with existing SFP+ infrastructure.
Key Features
- 10 Gigabit data rate with 10GBASE-SR protocol support
- 850nm wavelength optimized for multimode fiber performance
- Extended reach up to 300 meters on OM3/OM4 multimode fiber
- LC duplex connector for standard network equipment compatibility
- Wide operating temperature range: 0°C to +70°C
- Hot-pluggable SFP+ form factor for flexible deployment
- Low power consumption with passive thermal management
- RoHS compliant and environmentally responsible design
Technical Specifications
| Specification |
Details |
| Manufacturer |
Ribbon |
| Part Number |
SBC-SFPMM-10G-S |
| Transceiver Type |
SFP+ SR (Short Range) |
| Data Rate |
10 Gigabit (10G) |
| Protocol |
10GBASE-SR |
| Wavelength |
850nm |
| Fiber Type |
Multimode (OM3/OM4) |
| Maximum Distance |
300 meters |
| Connector Type |
LC Duplex |
| Operating Temperature |
0°C to +70°C |
| Form Factor |
SFP+ (Small Form-Factor Pluggable) |
| Compliance |
RoHS, IEEE 802.3ae |
Frequently Asked Questions
What is an SFP+ SR transceiver used for?
An SFP+ SR transceiver is used for short-range, high-speed fiber optic connections in data centers and enterprise networks. The SR (Short Range) variant operates at 850nm over multimode fiber, providing cost-effective 10 Gigabit connectivity for distances up to 300 meters, making it ideal for intra-building and campus network applications.
What is the difference between 10GBASE-SR and other 10G standards?
10GBASE-SR is optimized for short-range multimode fiber transmission at 850nm wavelength. Unlike 10GBASE-LR (long-range, single-mode, 1310nm), SR transceivers are more affordable and suitable for shorter distances. The Ribbon SBC-SFPMM-10G supports up to 300 meters on OM3/OM4 multimode fiber, making it perfect for data center environments.
Is the Ribbon SBC-SFPMM-10G compatible with my network equipment?
Yes, the SBC-SFPMM-10G features a standard LC duplex connector and SFP+ form factor, ensuring compatibility with most enterprise switches, routers, and network interface cards that support 10GBASE-SR. Its hot-pluggable design allows easy installation without equipment downtime.
What fiber type should I use with this 850nm multimode transceiver?
The Ribbon SBC-SFPMM-10G is designed for OM3 or OM4 multimode fiber. OM3 supports up to 300 meters at 10G speeds, while OM4 provides enhanced performance margins. Ensure your fiber infrastructure meets these specifications for optimal 10GBASE-SR performance and maximum 300-meter reach.
