This switched PDU is perfect for data center managers, IT administrators, and network engineers who need intelligent power distribution with remote outlet control and comprehensive monitoring. Our rack mount PDU delivers:
-
Switched power distribution unit with individual outlet on/off control for remote power cycling
-
Smart PDU monitoring with real-time power consumption tracking and environmental sensors
-
Rack mount PDU design optimized for standard 19-inch server racks and data centers
-
Network monitored PDU with web interface, SNMP, and API integration capabilities
Key Features
- Advanced switched power distribution unit with individual outlet control
- Professional rack mount PDU with 1U form factor for space efficiency
- Comprehensive smart PDU monitoring with power metering and environmental sensing
-
Network monitored PDU with secure web interface and SNMP support
-
Metered PDU capabilities with real-time power consumption display
- Intelligent outlet sequencing and power cycling automation
- Environmental monitoring with temperature and humidity sensors
- Multi-user access control with role-based permissions
Technical Specifications
| Manufacturer |
Raritan |
| Model Number |
PX3-5434R |
| Product Line |
Dominion PX |
| Type |
Switched Rack Mount PDU |
| Form Factor |
1U Horizontal Rack Mount |
| Input Voltage |
208V AC Single Phase |
| Input Current |
20A Maximum |
| Input Frequency |
50/60 Hz |
| Input Connection |
NEMA L6-20P (Twist-Lock) |
| Output Outlets |
8x C13 + 4x C19 IEC Outlets |
| Outlet Control |
Individual On/Off Switching |
| Power Rating |
4.1kW @ 208V |
| Circuit Breakers |
20A Input Circuit Breaker |
| Power Monitoring |
Per-outlet and total power metering |
| Current Monitoring |
RMS current measurement per outlet |
| Voltage Monitoring |
RMS voltage monitoring |
| Power Factor |
True power factor measurement |
| Energy Monitoring |
kWh energy consumption tracking |
| Environmental Sensors |
Integrated temperature and humidity sensors |
| Network Interface |
10/100 Mbps Ethernet |
| Network Protocols |
HTTP/HTTPS, SNMP v1/v2c/v3, SSH, Telnet |
| API Support |
RESTful API and JSON-RPC |
| User Interface |
Web-based GUI with responsive design |
| Security Features |
SSL/TLS encryption, user authentication, role-based access |
| Outlet Sequencing |
Configurable power-on/off delays |
| Alarm Thresholds |
Configurable current, power, and environmental alarms |
| Data Logging |
Historical data storage and trending |
| Operating Temperature |
0°C to 50°C (32°F to 122°F) |
| Storage Temperature |
-25°C to 65°C (-13°F to 149°F) |
| Humidity |
8% to 90% Non-Condensing |
| Dimensions (WxDxH) |
17.2" x 20.5" x 1.7" (437 x 521 x 44 mm) |
| Weight |
8.8 lbs (4.0 kg) |
| Mounting |
Standard 19" rack mount with included brackets |
| Certifications |
UL, cUL, CE, FCC, RoHS |
| Warranty |
3 Years Standard Hardware Warranty |
| MTBF |
>200,000 hours |
| Compatible Applications |
Servers, switches, storage systems, network equipment |
Advanced Switching & Control
The switched power distribution unit provides comprehensive outlet control for remote power management:
Individual Outlet Control:
-
Remote Power Cycling: Restart unresponsive equipment without physical access
-
Sequential Startup: Configurable power-on delays prevent inrush current spikes
-
Graceful Shutdown: Coordinated power-off sequences for proper system shutdown
-
Emergency Power Off: Immediate shutdown capability for emergency situations
Automated Power Management:
-
Threshold-Based Actions: Automatic outlet control based on power or environmental conditions
-
Scheduled Operations: Time-based power cycling and maintenance windows
-
Load Shedding: Automatic non-critical load disconnection during power emergencies
-
Dependency Mapping: Define power-on relationships between connected equipment
Comprehensive Power Monitoring
The metered PDU capabilities provide detailed power analytics for optimal data center management:
Real-Time Monitoring:
-
Per-Outlet Metering: Individual power consumption tracking for each outlet
-
Total Power Monitoring: Overall PDU power consumption and efficiency metrics
-
Current Measurement: RMS current monitoring with configurable alarm thresholds
-
Voltage Monitoring: Continuous voltage level tracking and regulation verification
-
Power Factor Analysis: True power factor measurement for load optimization
Energy Analytics:
-
kWh Tracking: Historical energy consumption data for cost analysis
-
Trend Analysis: Long-term power usage patterns and capacity planning
-
Peak Demand: Maximum power consumption recording and alerts
-
Carbon Footprint: CO2 emission calculations based on power consumption
Network Management & Integration
The network monitored PDU provides enterprise-grade management capabilities:
Network Connectivity:
-
Ethernet Interface: 10/100 Mbps network connectivity for remote management
-
Web Interface: Intuitive browser-based GUI with responsive design
-
SNMP Support: Full SNMP v1/v2c/v3 for network management system integration
-
API Access: RESTful API and JSON-RPC for custom application development
Security & Access Control:
-
User Authentication: Local and LDAP/Active Directory authentication support
-
Role-Based Access: Granular permissions for different user types
-
SSL/TLS Encryption: Secure communications for all network traffic
-
Access Logging: Comprehensive audit trails for security compliance
Environmental Monitoring
Integrated environmental sensors provide comprehensive smart PDU monitoring beyond power metrics:
Environmental Capabilities:
-
Temperature Monitoring: Real-time rack temperature measurement
-
Humidity Sensing: Relative humidity tracking for equipment protection
-
Threshold Alarms: Configurable environmental alerts and notifications
-
Sensor Expansion: Support for additional external environmental sensors
Data Center Intelligence:
-
Hot Spot Detection: Identify thermal issues before equipment damage
-
Trend Analysis: Historical environmental data for HVAC optimization
-
Capacity Planning: Environmental load analysis for expansion decisions
-
Compliance Reporting: Environmental data for regulatory compliance
Data Center Applications
This enterprise rack mount PDU is engineered for demanding data center environments:
Server Infrastructure:
-
Blade Servers: Individual chassis power control and monitoring
-
Rack Servers: Per-server power cycling and consumption tracking
-
Storage Arrays: Controlled startup sequences for SAN and NAS systems
-
Network Equipment: Switch and router power management and monitoring
Virtualization Environments:
-
Hypervisor Hosts: Physical host power management for VM migration
-
Cluster Management: Coordinated power control for high-availability clusters
-
Resource Optimization: Power consumption data for VM placement decisions
-
Maintenance Windows: Automated power sequencing for planned maintenance
Installation & Deployment
Professional rack mount PDU installation with enterprise-grade features:
Physical Installation:
-
1U Rack Mount: Compact design fits in standard 19-inch equipment racks
-
Horizontal Mounting: Space-efficient installation between server equipment
-
Cable Management: Integrated cable routing for clean installations
-
Tool-Free Setup: No additional tools required for basic installation
Network Configuration:
-
Zero-Touch Provisioning: Automated network configuration capabilities
-
Discovery Protocols: Automatic device discovery and inventory
-
Bulk Configuration: Template-based setup for multiple units
-
Remote Deployment: Complete setup and configuration without physical access
Management Software Integration
Comprehensive software ecosystem for smart PDU management:
Raritan Software Suite:
-
Power IQ: Enterprise power management and monitoring software
-
EMX: Environmental monitoring and alerting platform
-
Xerus: Mobile app for remote PDU management
-
CommandCenter: Centralized management for multiple PDUs
Third-Party Integration:
-
DCIM Platforms: Integration with leading data center management tools
-
Monitoring Systems: SNMP integration with network monitoring platforms
-
Ticketing Systems: Automated alert integration with IT service management
-
Virtualization Platforms: VM-aware power management capabilities
Target Use Cases
This professional switched power distribution unit serves diverse enterprise applications:
Enterprise Data Centers:
- Corporate server rooms requiring remote power management
- Colocation facilities with multi-tenant power control needs
- Cloud service providers managing large server deployments
- Financial services with strict uptime and monitoring requirements
Edge Computing:
- Distributed computing locations requiring remote management
- Retail environments with unattended IT equipment
- Manufacturing facilities with industrial control systems
- Telecommunications sites with critical network infrastructure
Frequently Asked Questions
Q: What makes this a switched power distribution unit and how does switching benefit my data center?
A: This switched PDU provides individual on/off control for each outlet, allowing remote power cycling of unresponsive equipment, scheduled maintenance operations, and emergency load shedding. The switching capability eliminates the need for physical data center visits to restart equipment, significantly reducing operational costs and improving uptime.
Q: How does the power monitoring help with data center energy management?
A: The metered PDU provides per-outlet power consumption data, allowing precise tracking of equipment energy usage. This smart PDU monitoring enables capacity planning, cost allocation, energy efficiency optimization, and identification of power-hungry equipment that may need optimization or replacement.
Q: What network management capabilities does this rack mount PDU offer?
A: This network monitored PDU includes web interface, SNMP v1/v2c/v3, RESTful API, and JSON-RPC protocols for comprehensive integration. It supports secure authentication, role-based access control, and can integrate with existing network management systems, DCIM platforms, and automated provisioning tools.
Q: How does the environmental monitoring enhance data center operations?
A: The integrated temperature and humidity sensors provide real-time environmental data, enabling hot spot detection, HVAC optimization, and proactive equipment protection. Combined with power monitoring, this environmental data helps optimize cooling efficiency and prevent equipment damage from thermal issues.
Q: Can this switched power distribution unit integrate with virtualization platforms?
A: Yes, the smart PDU APIs and SNMP capabilities enable integration with virtualization management platforms. This allows VM-aware power management, coordinated host power cycling during VM migration, and power consumption data for optimized VM placement and resource allocation decisions.
Q: What installation options are available for this rack mount PDU?
A: The 1U rack mount PDU design fits standard 19-inch racks with included mounting brackets. It features horizontal mounting for space efficiency, integrated cable management, and network connectivity for zero-touch provisioning and remote configuration without requiring physical data center access.
