This monitored rack PDU is perfect for data center managers and IT professionals who need precise energy metering and reliable power distribution for critical server infrastructure. Our Raritan PX3 series delivers:
-
Real-time energy metering providing detailed power consumption analytics
-
208V power distribution optimized for high-density server environments
-
Intelligent PDU monitoring with remote management capabilities
-
1U rack mount design maximizing space efficiency in server cabinets
Key Features
-
5kVA power capacity supporting multiple high-power server loads
-
Energy metering technology with precise measurement and reporting
- Advanced power distribution unit with outlet-level monitoring
-
208V input configuration with NEMA L6-30P 30A plug connection
-
Mixed outlet types including 4x C13 and 4x C19 IEC connections
-
1U horizontal form factor optimized for rack space efficiency
-
Network management capabilities for remote monitoring and control
Technical Specifications
| Manufacturer |
Raritan |
| Model Number |
PX3-4198R-F1C5 |
| Type |
Monitored Rack Power Distribution Unit |
| Power Capacity |
5kVA, 30A |
| Input Voltage |
208V single-phase |
| Input Connection |
NEMA L6-30P plug (2P3W) |
| Output Outlets |
4x C13, 4x C19 IEC outlets |
| Form Factor |
1U horizontal rack mount |
| Monitoring Features |
Energy metering, outlet monitoring |
| Network Management |
Ethernet interface with web GUI |
| Installation |
Standard 19-inch rack mount |
| Operating Temperature |
32°F to 104°F (0°C to 40°C) |
| Compatible Systems |
Servers, network equipment, storage systems |
| Warranty |
2 years manufacturer warranty |
Frequently Asked Questions
Q: What makes this monitored rack PDU different from basic power strips?
A: This intelligent PDU provides real-time energy metering and monitoring capabilities, allowing you to track power consumption at both the unit and outlet level — essential for data center capacity planning and energy management.
Q: Can I monitor this PDU remotely?
A: Yes, the Raritan PX3 features built-in network connectivity with web-based management interface, SNMP support, and integration with data center infrastructure management (DCIM) systems for comprehensive remote monitoring.
Q: What type of servers and equipment can I connect to this 208V PDU?
A: This 208V power distribution unit is designed for high-density server environments and can power enterprise servers, storage arrays, and network equipment requiring higher voltage for improved efficiency.
Q: How accurate is the energy metering on this unit?
A: The energy metering system provides ±1% accuracy for voltage, current, and power measurements, meeting industry standards for data center power monitoring and billing applications.
Monitored Rack PDU 208V by Raritan PX3. 1U horizontal mount with energy metering, 5kVA capacity, and intelligent monitoring for data centers.
