Mfr Part Number: TS-432PXU-RP-2G-US
-
CPU: AnnapurnaLabs Alpine AL324 64-bit ARM Cortex-A57 quad-core 1.7GHz processor
-
CPU Architecture: 64-bit ARM
-
Floating Point Unit: Yes
-
Encryption Engine: Yes
-
System Memory: 2 GB UDIMM DDR4 (1 x 2 GB)
-
Maximum Memory: 16 GB (1 x 16 GB)
-
Memory Slot: 1 x Long-DIMM DDR4
-
Flash Memory: 512 MB (Dual boot OS protection)
-
Drive Bay: 4 x 3.5" SATA 6Gb/s, 3Gb/s
-
Drive Compatibility: 3.5-inch bays:
-
3.5-inch SATA hard disk drives
-
2.5-inch SATA hard disk drives
-
2.5-inch SATA solid state drives
-
Hot-swappable: Yes
-
M.2 SSD Slot: Optional via a PCIe adapter
-
SSD Cache Acceleration Support: Yes
-
2.5 Gigabit Ethernet Port (2.5G/1G/100M): 2 (also support 10M)
-
10 Gigabit Ethernet Port: 2 x 10GbE SFP+
-
Wake on LAN (WOL): Yes, Only the 2.5GbE port
-
Jumbo Frame: Yes
-
PCIe Slot: 1
-
USB 3.2 Gen 1 port: 4
-
Form Factor: 1U Rackmount
-
LED Indicators: HDD 1-4, Status, LAN, Storage expansion
-
Buttons: Power, Reset
-
Operating temperature: 0 - 40 C (32F - 104F)
-
Storage Temperature: -20 - 70C (-4F - 158F)
-
Relative Humidity: 5-95% RH non-condensing, wet bulb: 27C (80.6F)
-
Power Supply Unit: 250W (x2) PSU, 100 - 240V
-
Power Consumption: Operating Mode, Typical: 53.343 W. Tested with drives fully populated
-
Fan: 2 x 40mm, 12VDC
-
Sound Level: 39 db(A)
-
System Warning: Buzzer
-
Max. Number of Concurrent Connections (CIFS) - with Max. Memory: 700
-
Dimensions (HxWxD): 1.73 17.28 19.65 inch
-
Weight: 17.9 lbs
