Qnap Qxp-W6-Ax200 Network Card Wlan / Bluetooth 2400 Mbit/S

Wi-Fi, PCIe x1 2.0, 2.4G, 5GHz, 2T x 2R

QNAP QXP-W6-AX200. Connectivity technology: Wireless, Host interface: PCI Express, Interface: WLAN / Bluetooth. Maximum data transfer rate: 2400 Mbit/s, Top Wi-Fi standard: Wi-Fi 6 (802.11ax), Wi-Fi band: Dual-band (2.4 GHz / 5 GHz)

The QXP-W6-AX200 is a PCIe Gen 2x1 Wi-Fi 6 wireless adapter with an Intel Wi-Fi 6 AX200 module that supports the IEEE 802.11ax standard (backwards compatible with 802.11a/b/g/n/ac), MIMO 2Tx2R, MU-MIMO TX/RX and Bluetooth 5.0. The QXP-W6-AX200 can be installed in a QNAP NAS, or Windows/Linux PC to provide fast Wi-Fi 6 connection speeds The QXP-W6-AX200 can also be used with Wi-Fi 6 router to deploy Wi-Fi 6 network environment. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included.

2.8x Faster Connectivity
The QXP-W6-AX200 dual band Wi-Fi 6 PCIe card supports 802.11ax 160MHz dual band connectivity, 1024-QAM and up to 2400Mbps connection speed which is 2.8 times faster than Wi-Fi 5(802.11ac).

Easy Access with a Wireless NAS
With a QXP-W6-AX200 installed in your NAS, you can free yourself from Ethernet cables and access all your stored files and multimedia over a high-speed wireless connection. A full-height bracket is pre-installed on the QXP-W6-AX200 and two low-profile brackets are also included.

Easily Set Up a NAS Wireless Network Connection
After installing the QXP-W6-AX200 in your NAS, use Network & Virtual Switch or Qfinder Pro to set up the Wi-Fi connection, guest network environment or captive portal.

Upgrade Your Windows or Linux PC with High-speed Wireless Networking!
The QXP-W6-AX200 is not just for NAS, it can be installed in a Windows or Linux PC to provide Wi-Fi 6 connectivity for enabling faster downloading speeds and low-latency connectivity.

Dual Band Antenna with Better Wi-Fi Signals
The QXP-W6-AX200 features a new antenna design that provides better Wi-Fi signals and transmission speeds.

Supports dual band 802.11ax 2.4GHz & 5GHz and provides better signal strength compared to traditional antenna designs.
The smart antenna function provides superior WI-FI signal transmission.
The multiple angle tilt and magnetic base allows you to get the best signal strength direction and location.

Add Bluetooth 5.0 to Your Windows PC
When installed in a Windows PC, the QXP-W6-AX200 provides Bluetooth 5.0 connectivity. Please note that this requires connecting the QXP-W6-AX200 to an F_USB connector on your motherboard using the included USB cable.
