Qnap Nvr Server X Smart Poe Switch, Building Complete Surveillance Network

QNAP NVR Server X Smart PoE Switch, Building Complete Surveillance Network

The QVP-41B NVR network surveillance server supports real-time video/audio monitoring, high-resolution recording, and playback from multiple IP cameras. PoE switch functionality is also provided by the QVP-41B, supporting connecting all kinds of PoE cameras and devices and creating intelligent surveillance infrastructure for enterprise, SMBs and families. With four 3.5-inch SATA drive bays, sixteen 30-watt Gigabit PoE ports, two RJ45 combo ports, and two 2.5GbE host management ports the QVP-41B provides great storage space and high-speed networking to meet the requirements of small/medium monitoring environments.

•
  1

  Supports thousands of cameras from over 150 brands.

•
  2

  Compliant with the IEEE 802.3at PoE+ standard and includes sixteen 30-watt Gigabit PoE ports. Supplies a total power budget of 140 watts to meet the demands of high-powered devices (PDs) and supports smart PoE management.

•
  3

  Monitor surveillance feeds with the built-in QVR Smart Client through HDMI output, Windows®, Mac® and mobile devices.

QVP-41B vs. other NAS-based surveillance systems. What's the difference?

In a conventional NAS-based surveillance system, surveillance is just one of many applications available to users. As all these applications share NAS system resources and storage space, surveillance performance could be impacted. The QVP-41B overcomes this by providing dedicated storage space and reserving full system resources for surveillance, delivering the utmost performance to fulfill professional surveillance system requirements. The QVP-41B integrates PoE switch functionality and supports connecting all kinds of PoE cameras and devices. It also comes with built-in camera channel licenses and essential applications to enable local installation without requiring an internet connection. Simply install the hard drives and power up the QVP-41B to start the installation process.

Intelligent PoE Management for High-Power IP Cameras

The QVP-41B is compliant with the IEEE 802.3at PoE+ standard and has sixteen ports with 30-watt Gigabit PoE capabilities. The QVP-41B can supply a total power budget of 140 watts to meet the demands of bullet cameras, fisheye cameras, 4K PTZ cameras and Speed Dome cameras compliant with the ONVIF® standard; or high-power devices such as 4K PTZ camera, IP phones, LED lights, and digital signage. The QVP-41B supports intelligent PoE management functions, including scheduling, power supply prioritization, and power enabling/disabling. You can obtain real-time network connection status and power consumption information of PDs and configure PDs simultaneously to promote an energy-saving PoE network.

• PoE power: 15-30-watt Gigabit PoE capabilities to high-power IP cameras.


• Camera management: QUSBCam2 allows using USB cameras and webcams as ONVIF® cameras.


• Storage backup: Install four 3.5-inch SATA drives to attain large storage space for backup.


• Surveillance server: QVR Pro is compatible with a wide range of ONVIF® IP cameras and allows central management of live feeds and recordings.


• Video output: Connect the QVP-41B via HDMI output to a 4K display for direct playback of security footage.


• Surveillance video: Simultaneously view live feeds and recordings via the QVR Pro Client


• Fiber uplink: 1GbE SFP/RJ45 combo port to connect to a backbone network or data center.


• Central management: Use QVR Center to manage multiple instances of QVR Pro.


• Surveillance failover: QVR Guard automatically takes over recording tasks if a QVR Pro server fails.

Product Type: Video Surveillance Station
Nvr Weight: 8.99 lb
Brand Name: QNAP
Manufacturer: QNAP Systems
Product Model: QVP-41B
Product Name: NVR Server X Smart PoE Switch, Building Complete Surveillance Network
Manufacturer Part Number: QVP-41B-8G-P-US
Manufacturer Website Address: http://www.qnap.com
Package Contents:

• NVR Server X Smart PoE Switch, Building Complete Surveillance Network
• Power Cord
• 16 x Flat Head Screw (for 3.5" HDD)
• 12 x Flat Head Screw (for 2.5" HDD)
• 2 x Drive Tray Keys
• Ethernet Cable
• Quick Installation Guide (QIG)
