Perle PSI-MOS-RS485W2/FO1300 E Transceiver/Media Converter
The PSI-MOS-RS485W2/FO 1300 E can be used to convert RS485 2-wire devices to fiber optics. By transmitting serial data over optical fiber, these serial media converters provide an economical path to extend the reach of RS485 devices. All protocols with 10/11-bit UART data format and NRZ data coding are supported. This includes popular protocols such as:
- Modbus ASCII / MODBUS RTU
- SUCONET K
- S-BUS
- DH-485, and more...
Long Distance Serial Data Transmission over Fiber RS485 Serial transmission is commonly limited to 100 kbps over a distance of only 1200 meters (4000 feet). Using the FO 1300 E Serial to Fiber Converter you can extend your serial data transmission up to 27km (16.7 miles) over multimode fiber or 45km (28 miles) over single mode fiber. The result is that any two pieces of asynchronous serial equipment, located miles apart, can communicate at half duplex over fiber optic cable at rates up to 500 kbps.
EMI, RFI and Transient Surge Immunity Another advantage of the FO 1300 E fiber optic transmission system is the electrically isolated connection of devices. Electromagnetic interference (EMI) is a common phenomenon in typical environments like industrial plants, warehouses and factory floors. This interference can cause corruption of data over RS485 or copper-based Ethernet links. Data transmitted over fiber optic cable however is completely immune to this type of noise, thus preventing the negative effects of voltage equalization currents and electromagnetic interference on the data cables. A Serial to Fiber Media Converter therefore enables you to inter-connect your serial devices over fiber ensuring optimal data transmission, increased availability of the system, and improved network design flexibility for point-to-point connections and star structures.
Flexible Fiber Optic Connections The FO 1300 E operates at 1300 nm wavelength, using a separate LED emitter and photo-detector on SC type connectors. Almost any multimode or single mode glass fiber size can be used.
Power Budget Considerations Calculating the power budget is critically important with planning the fiber optic link. The optical power budget is the amount of light required to transmit data successfully over distance through a fiber-optic connection. The amount of light energy available within the setup will dictate the length of the fiber optic cable run between serial media converters within the network. Optical power budgets are critical to help businesses avoid signal distortion.To learn how to calculate optical power budget read our technical note. Transmit and receive dBm can be found in the Hardware specifications.
Transmit each serial signal out over 10 fiber optic lines Up to ten (10) Serial to Fiber Converters can be grouped together using the TBUS DIN Rail bus system for voltage and data. This allows the serial converter to operate as a star coupler, taking the serial data input signal and distributing it to all Fiber optic output ports.
- Extend serial data up to 28 miles
- Immune to EMI, RFI and transient surges
- Point-to-point or star configuration
- SC type fiber connectors
- Terminal Block for 2-wire RS485 Connections
Product Type: Transceiver/Media Converter
Environmentally Friendly: Yes
Environmental Certification: REACH
Country Of Origin: Germany
Brand Name: Perle
Form Factor: Rail-mountable
Manufacturer: Perle Systems, Inc
Product Model: PSI-MOS-RS485W2/FO1300 E
Product Name: PSI-MOS-RS485W2/FO1300 E Transceiver/Media Converter
Manufacturer Part Number: 27085624
Manufacturer Website Address: http://www.perle.com
Packaged Quantity: 1
Package Contents:
- PSI-MOS-RS485W2/FO1300 E Transceiver/Media Converter
- 24VDC USA Wall Power Adapter
Limited Warranty: 1 Year
Weight (Approximate): 7.39 oz
