Bosch NPD-5001-POE Midspan PoE Injector

Bosch Midspan, 15W, Single Port, AC In

This power injector allows an existing Ethernet infrastructure to be enhanced for use with PoE cameras.

System overview

The NPD-5001-POE is a single-port power injector that supplies one PoE camera with power.

Functions

The injector converts the AC input power to a +48 VDC power supply which is then provided to the cameras via the Ethernet cable. They support up to 10/100/1000 Mbps pass-through data rates. Each injector provides up to 15.4 W per port. The PoE midspan injector unit can be easily mounted on a shelf, wall or ceiling

Product Type: PoE Injector
Environmentally Friendly: Yes
Environmental Certification: GS
Certifications & Standards:

• FCC Part 15, Class B
• EN 60950
• EN 55022 class B
• EN 55024
• IEEE 802.3af

Brand Name: Bosch
Compatibility: PoE Cameras
Form Factor: External
Length: 5.5"
Manufacturer: The Bosch Group
Product Model: NPD-5001-POE
Product Name: Midspan, 15W, Single Port, AC In
Mount Type: Shelf/Wall/Ceiling-mountable
Manufacturer Part Number: NPD-5001-POE
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Package Contents:

• NPD-5001-POE Midspan PoE Injector
• Power Cord

Weight (Approximate): 7.05 oz
