Bosch NPD-5004-POE Midspan PoE Injector

Bosch Midspan, 4 Port x 15W, AC In

This power injector allows an existing Ethernet infrastructure to be enhanced for use with PoE cameras.

System overview

The NPD-5004-POE four-port power injector can supply four individual PoE cameras with power.

Functions

The injector converts the AC input power to a +48 VDC power supply which is then provided to the cameras via the Ethernet cable. They support up to 10/100/1000 Mbps pass-through data rates. Each injector provides up to 15.4 W per port. The PoE midspan injector unit can be easily mounted on a shelf, wall or ceiling

Product Type: PoE Injector
Environmentally Friendly: Yes
Environmental Certification: GS
Country Of Origin: Philippines
Certifications & Standards:

• FCC Part 15, Class B
• EN 60950
• EN 55022 class B
• EN 55024
• IEEE 802.3af

Brand Name: Bosch
Compatibility: PoE Cameras
Form Factor: External
Length: 5.5"
Manufacturer: The Bosch Group
Product Model: NPD-5004-POE
Product Name: Midspan, 4 Port x 15W, AC In
Mount Type: Shelf/Wall/Ceiling-mountable
Manufacturer Part Number: NPD-5004-POE
Manufacturer Website Address: http://www.bosch.com
Packaged Quantity: 1
Package Contents:

• NPD-5004-POE Midspan PoE Injector
• Power Cord

Weight (Approximate): 1.37 lb
