Microchip 1-Port 30W 802.3at PoE Injector
Microsemi's PD-9001GR is a single port, high-power solution for remote powering of current and emerging high power applications. Generating up to 30W, the PD-9001GR enables remote power for a new range of applications including 802.11ac Access Points, pan-tiltzoom (PTZ) cameras and video-phones. It complies with the IEEE 802.3at PoE+ standard and is backward compatible with IEEE802.3af. It can power both existing 10/100Base-T network devices and emerging wireless 1000Base-T devices such as wireless IEEE 802.11ac access points and IP Cameras.
Features
- Single-port Gigabit PoE Midspan, 802.3at Compliant with 2-event classification
- Backwards compatible with IEEE802.3af
- 30W output power from -20C to +40C, 25W output at +55C
- 1000Base-T compatible
- Safe & reliable power over existing Ethernet infrastructure, only PoE devices receive power
- Automatic detection and protection of non-standard devices
- Plug-and-play installation
- Guaranteed up-time
Product Type: PoE Injector
Environmentally Friendly: Yes
Environmental Certification: GS
Certifications & Standards:
- CE
- FCC Part 15, Class B
- EN 55022 Class B (Emissions)
- EN 55024 (Immunity)
- VCCI
- UL/cUL Per IEC 60950-1
- IEEE802.3af
- IEEE802.3at
Brand Name: Microchip
Compatibility:
- Access Points
- Pan-Tiltzoom (PTZ) Cameras
- Video-Phones
- Network Devices
Length: 5.5"
Manufacturer: Microchip Technology Inc.
Product Model: PD-9001GR
Product Name: 1-Port 30W 802.3at PoE Injector
Manufacturer Part Number: PD-9001GR/AT/AC-US
Manufacturer Website Address: http://www.microchip.com
Limited Warranty: 1 Year
Weight (Approximate): 7.04 oz
