Parsec PRO Bulldog MIMO Antenna - Ceiling Tile Mount
The Parsec PRO Bulldog MIMO antenna is a professional-grade ceiling tile-mounted solution designed for enterprises requiring robust multi-band connectivity. This 4 LTE and 4 WiFi MIMO antenna delivers simultaneous dual-band performance with integrated 2-foot cables and SMA/RP-SMA connectors, making it ideal for office buildings, retail locations, and industrial facilities needing seamless indoor coverage without visible external installations.
Built for reliability and ease of installation, the white finish integrates seamlessly into standard ceiling tile environments while providing enterprise-class signal strength across LTE and WiFi networks.
Key Features
- 4 LTE antenna elements with SMA male connectors for cellular coverage
- 4 WiFi antenna elements with RP-SMA male connectors for wireless networks
- MIMO technology for improved signal diversity and throughput
- Ceiling tile mounting design for discreet indoor installation
- 2-foot pre-attached cables for convenient deployment
- White finish for seamless integration with office environments
- Professional-grade construction for enterprise applications
- Dual-band performance for simultaneous LTE and WiFi connectivity
Technical Specifications
| Specification |
Details |
| Manufacturer |
PARSEC TECHNOLOGIES |
| Part Number |
PRO8BD4L4W02 |
| Product Type |
MIMO Antenna - Ceiling Tile Mount |
| Color |
White |
| LTE Connectors |
4x SMA Male |
| WiFi Connectors |
4x RP-SMA Male |
| Cable Length |
2 feet (pre-attached) |
| Mounting Style |
Ceiling Tile |
| Technology |
MIMO (Multiple-Input Multiple-Output) |
Frequently Asked Questions
What is a MIMO antenna and why does it matter?
MIMO (Multiple-Input Multiple-Output) technology uses multiple antenna elements to transmit and receive data simultaneously, significantly improving signal quality, coverage, and data throughput compared to single-antenna solutions. The Parsec PRO Bulldog MIMO antenna with 4 LTE and 4 WiFi elements maximizes performance in multi-user environments.
Is this ceiling tile antenna suitable for office buildings?
Yes. The white finish and ceiling tile mounting design make this 4 LTE 4 WiFi MIMO antenna perfect for office environments where aesthetics matter. It installs directly into standard drop ceilings without requiring external wall or roof penetrations.
What connector types are included?
The antenna includes 4 SMA male connectors for LTE connections and 4 RP-SMA male connectors for WiFi connections, with 2-foot pre-attached cables for straightforward integration into existing infrastructure.
Can I use this antenna for both cellular and WiFi simultaneously?
Yes. The Parsec PRO Bulldog dual-band MIMO antenna supports simultaneous LTE and WiFi operation, allowing your devices to maintain cellular and wireless network connectivity at the same time for enhanced redundancy and performance.
