Parsec Doberman PRO5DM2L2WGG-L 5-in-1 MIMO 5G LTE Antenna
The Parsec Doberman PRO5DM2L2WGG-L is a high-performance 5-in-1 omnidirectional antenna engineered for demanding industrial and professional applications requiring simultaneous MIMO 5G LTE, dual-band MIMO WiFi, and GNSS connectivity. This integrated antenna solution delivers CAT 18 cellular capability, making it ideal for enterprises deploying advanced LTE and 5G networks in challenging environments. With its gray dome housing and 15-foot LMR240 cable, the Doberman antenna provides reliable, multi-band coverage for IoT, mobile broadband, and location-based services without requiring separate antenna installations.
Key Features
- 5-in-1 integrated design: MIMO 5G LTE + dual-band MIMO WiFi + GNSS in single unit
- CAT 18 LTE support for maximum cellular performance and future 5G readiness
- Omnidirectional radiation pattern for 360° coverage in all environments
- Professional-grade gray dome housing for industrial installations
- 15-foot LMR240 low-loss cable for extended deployment flexibility
- Simultaneous multi-band operation reduces cable clutter and installation complexity
- GNSS positioning capability for asset tracking and location services
- Compact form factor suitable for rooftop, wall-mount, and mobile platform installations
Technical Specifications
| Specification |
Details |
| Manufacturer |
PARSEC TECHNOLOGIES |
| Part Number |
PRO5DM2L2WGG-L |
| Product Type |
5-in-1 Omnidirectional Antenna |
| Antenna Technology |
MIMO 5G LTE, MIMO WiFi (2.4/5 GHz), GNSS |
| Cellular Standard |
CAT 18 LTE / 5G Ready |
| Housing Color |
Gray |
| Cable Type |
LMR240 |
| Cable Length |
15 feet |
| Radiation Pattern |
Omnidirectional |
| Application |
Industrial, Professional, IoT, Mobile Broadband |
Frequently Asked Questions
What is a 5-in-1 MIMO antenna and why do I need one?
A 5-in-1 MIMO antenna combines multiple connectivity technologies into a single device: MIMO 5G LTE for cellular, dual-band MIMO WiFi for wireless networking, and GNSS for positioning. This integrated approach eliminates the need for separate antennas, reduces installation costs, minimizes cable management, and provides seamless multi-band coverage for IoT devices, mobile gateways, and industrial equipment.
Is the Parsec Doberman antenna suitable for outdoor 5G deployments?
Yes. The Doberman PRO5DM2L2WGG-L is specifically designed for professional outdoor installations with CAT 18 LTE and 5G-ready capability. Its omnidirectional pattern, gray industrial housing, and 15-foot LMR240 cable make it ideal for rooftop, tower, and pole-mount applications in demanding environments requiring reliable cellular and broadband connectivity.
What does CAT 18 mean for LTE performance?
CAT 18 (Category 18) is an advanced LTE standard supporting download speeds up to 1.2 Gbps through carrier aggregation and advanced MIMO techniques. The Doberman antenna's CAT 18 capability ensures your network infrastructure is ready for next-generation mobile broadband and 5G transitions, providing future-proof connectivity for enterprise and industrial applications.
Can the Doberman antenna be used for asset tracking and location services?
Yes. The integrated GNSS antenna in the Doberman PRO5DM2L2WGG-L enables precise positioning and location-based services. Combined with its MIMO 5G LTE connectivity, this antenna is ideal for fleet management, IoT asset tracking, and location-aware applications requiring simultaneous cellular communication and GPS/GNSS positioning.
